iCON120TR/USB Intelligent controller for access control and Time & attendance for up to 2 doors with built in power supply and U

Specifications

Controller iCON120TR USB has the possibility to control one double sided or two one sided doors. It has two standardized inputs for readers with RFID card, PIN code, RFID+work code, biometric data or combinations between them.
In connection with the management the controller uses two types of modes – standalone(no communication) or with serial communication. In standalone mode adding and deleting cards is done by using Master card which can be activated by a user friendly software. In communication mode you can take advantage of the easy and fast USB communication for standalone mode or you can use the controller as a converter from RS485 to USB and connect up to 253 devices on one line. (iCON 1XX)
All settings can be made by using paid (Andromeda Pro) or free (Andromeda Tool) software, which can offer you many optional functions which are described in the functionality.

Functionality

• Standalone mode with Master card
• Standalone mode with USB communication
• Network communication over RS485 (up to 253 devices)
• Dual working mode – as controller and converter RS485 to USB at the same time.
• Time & attendance calculation with Andromeda Pro
• Control of one double sided or two one sided doors
• Management of paid services with Andromeda Pro – fitness, spa, auto park, hotels
• Ability to synchronize with fire alarm system (NO contact)
• Automatic activation of the outputs by predefined time schedule
• Supports 10 Time schedules for access control and 10 schedules for holidays
• Input / output settings by user
• Volatile memory and real time clock
• Ability to control a turnstile with antipassback function

Application
Controller iCON120TR USB is compact and easy for installation. The built in power supply saves additional power supply, wiring and voltage drop in the big objects. This makes it suitable for: residential , office and production buildings, elevators,....By using software Andromeda Pro you have the ability to count time & attendance, manage access groups, generate many reports and also to control paid services in fitness and spa center, paid auto park and a lot of others.
