Home > Products > Electrical Equipments > Explosion Proof Royal Electric Fans
Explosion Proof Royal Electric Fans
US$ 10 - 500
/ Piece
3 Pieces(Min. Order)
- Shanghai Port/Ningbo Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Electric Current Type | AC | Mounting | Wall Fan | |
| Place of Origin | Zhejiang, China | Brand Name | BELIN | |
| Model Number | BT35-11 | Voltage | 220/380v | |
| Power | 180-11000w | Air Volume | 400-28000m³/h | |
| Speed | 720-2900r/min | Certification | CE, ROHS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Explosion proof Axial Fan
| Parameter name | Parameter |
| Standard | GB 3836.1, GB3836.2, IEC60079 |
| Ex-Mark | Exd II BT4 |
| Rated Voltage | AC 220/380V |
| Thread | G3/4" |
| Cable Outer Diameter | Φ9mm~Φ14mm |
| Type | Model | Air Volumn(m³/h) | Pressure(Pa) | Speed(r/min) | Capacity(w) | Noise dB(A) | Weight(kg) |
| Wall or Fixed | 2.2C | 400 | 29 | 1450 | 25 | 54 | 11 |
| 3C | 1600 | 39 | 1450 | 60 | 63.5 | 14.5 | |
| 4B | 4000 | 98 | 960 | 250 | 64.6 | 28 | |
| 4C | 5200 | 149 | 1450 | 550 | 66 | 18.6 | |
| 5A | 6000 | 78 | 720 | 250 | 64 | 36.5 | |
| 5B | 7000 | 112 | 960 | 370 | 70 | 36.5 | |
| 5C | 7500 | 177 | 1450 | 750 | 75 | 43 | |
| 6A | 9500 | 88 | 720 | 550 | 69 | 46 | |
| 7A | 15000 | 137 | 720 | 1100 | 72 | 80 | |
| 8A | 22000 | 157 | 720 | 1500 | 77 | 98 | |
| Bracket | 2.2C | 400 | 29 | 1450 | 25 | 56 | 18.6 |
| 3C | 1600 | 39 | 1450 | 60 | 61.5 | 18.5 | |
| 4B | 4000 | 98 | 960 | 250 | 64.5 | 23 | |
| 4C | 5200 | 149 | 1450 | 550 | 70 | 18.6 | |
| 5A | 6000 | 89 | 720 | 250 | 64 | 65 | |
| 5B | 7000 | 112 | 960 | 370 | 69 | 50 | |
| 6A | 9500 | 88 | 720 | 550 | 69 | 55 | |
| 6B | 14000 | 196 | 960 | 1100 | 77 | 68.5 | |
| 7A | 14500 | 137 | 720 | 1100 | 71 | 93 | |
| 7B | 22000 | 196 | 960 | 2200 | 78 | 118 | |
| 7C | 25000 | 294 | 1450 | 3000 | 81 | 110 | |
| 8A | 23000 | 147 | 720 | 1500 | 77 | 98 | |
| Pipe | 2.5D | 2000 | 205 | 2900 | 370 | 77 | 10 |
| 3C | 1600 | 39 | 1450 | 60 | 61.5 | 14.5 | |
| 3.2D | 3000 | 207 | 2900 | 370 | 78.5 | 18 | |
| 4B | 3900 | 98 | 910 | 250 | 64 | 28 | |
| 4C | 5000 | 149 | 1450 | 550 | 69 | 18.6 | |
| 5B | 5500 | 112 | 960 | 370 | 70 | 36.5 | |
| 5C | 7000 | 177 | 1450 | 750 | 75 | 43 | |
| 6B | 10000 | 196 | 960 | 1100 | 77.5 | 79 | |
| 6C | 15000 | 294 | 1450 | 2200 | 80.5 | 83 | |
| 7A | 14000 | 137 | 720 | 1100 | 72 | 80 | |
| 7B | 18000 | 206 | 960 | 2200 | 79.5 | 102 | |
| 7C | 20000 | 343 | 1450 | 3000 | 81.5 | 103 | |
| 8A | 20000 | 157 | 720 | 1500 | 76.5 | 98 | |
| 8B | 25000 | 226 | 960 | 2200 | 80.5 | 112 | |
| 8C | 28000 | 394 | 1450 | 4000 | 81.5 | 122 |
|
|
