Facade Aluminum Composite Panel Guangzhou Aluminium Composite Panel

Specifications

facade aluminum composite panel guangzhou aluminium composite panel

1. Standard: according to GB/T 17748-2008 standard

2. Basic Material of facade aluminum composite panel guangzhou aluminium composite panel

1)   front side: aluminum alloy sheet coated with fluoro-carbon resin(PVDF) or polyester

      resin roasting painting
2)   Core material: nontoxic polyethylene, PE, FR, LDPE
3)   Back side: aluminum alloy sheet coated with polyester resin painting(PE)

3. Dimensions of facade aluminum composite panel guangzhou aluminium composite panel

a) Surface coating thickness: 30um
b) Aluminum alloy sheet thickness: 0.1mm, 0.12mm, 0.15mm, 0.18mm, 0.2mm, 0.3mm, 0.4mm, 0.45mm, 0.5mm
c) Thickness:2mm, 3mm, 4mm, 5mm, 6mm
d) Width: 1220mm, 1250mm, 1500mm, 1570mm
e) Length: 2440mm to 6000mmm
f ) Weight: 5.5kg/sqm based on 4mm thickness
g) Standard size: 1220 x 2440mm
f)Normal color:60 colors for Normal aluminum composite panel 7 colors for granite grain panel

Non-standard sizes and special colors are available, according to customers' requests

4. Characters of facade aluminum composite panel guangzhou aluminium composite panel

a) Super peeling strength

b) Excellent surface flatness and smoothness

c) Superior weather, corrosion, pollutant resistance

d) Even coating, various colors

e) Fireproof, excellent heat and sound insulation

f) Superior impact resistance

g) Lightweight and easy to process

h) Easy to maintain, self-clean

5. Application scope of facade aluminum composite panel guangzhou aluminium composite panel

a) Building exterior curtain walls

b) Decoration and renovation additions for old buildings

c) Decoration of interior walls, ceilings, bathrooms, kitchens and balconies

d) Shop door decorations

e) Advertisement board display platforms and signboards

f) Wallboards and ceilings for tunnels

g) Industrial materials, materials for vehicles and boats

6. Test reports ------- panel for indoor

Test Result -------panel for outdoor

7.  Factory Scope
