UHMWPE Coal Bunker Lining Sheet Self-lubricating

Ultra High Molecular Weight (UHMW) Polyethylene is often referred to as the world toughest polymer. Reinforced Ultra-high

molecular weight Polythene Board is a type of thermoplastic,which combines the advantage characteristics of all types of

plastic, featuring in the excellence of withstanding wear and tear, resisting impact and chemical corrosion, self-lubricating,

working against low temperature, being low in abrasion loss, light in weight,absorbing energy,antiageing, retarding inflaming

and preventing buildup of static electricity.It is widely used in the interior lining of coal house of thermo power plants,coal mines

and coking plants etc. the raw material storehouse of cement factories ,steel mills and aluminum factories ,the granary of food

industry,feedstuff industry and pharmaceutical factories as well the hoppers at wharfs.

1. UHMW-PE sheet size:

6100mm*1300mm*thickness10~200mm

2000mm*6000mm*thickness10~200mm

1500mm*7000mm*thickness10~200mm

1220mm*2440mm*thickness10~200mm

2. UHMW-PE rods size: diameter20mm-200mm length:1000mm

UHMWPE GRADE

1  Molecular weight:3million g/mol

2  Molecular weight:5.million g/mol

3  Molecular weight:9million g/mol

4  Molecular weight:9.2million g/mol

Features of plastic polyethylene sheet

1. abrasive resistance which always have in thermoelectricity polymer.
2. best shock resistance even in low temperature.
3. low frictional factor, and well sliding bearing material
4. lubricity( no caking, in adhesion)
5. best chemical corrosion resistance and stress craze resistance
6. excellent machinery process ability
7. lowest water absorption(<0.01%)
8. paragon electric insulativity and antistatic behavior
9. nice high energy radioactive resistance
10. density is lower than other thermoplastics (< 1g/m3)
11.  long using temperature range: -269°C--85°C
12.  Non-toxic:in accordance with FDA/USDA standard

Benefits:

1. Non-Toxic and smell

2. Low coefficient of friction

3. Corrosion resistant

4. Abrasion and impact resistant

5. Anti-Weather and Anti-Aging

6. Self-lubricating

7. Wear Resistant

8. Great liner material for industrial material handling applications

9. UV Resistant/ultraviolet-resistance sheet

10. High Operating Temperature

11. High Tensile Strength

12. High Viscosity

13. Flame Retardant

14. Reprocessed

Applications of plastic polyethylene sheet:

1.Lining: Silos, hoppers, wear-resistant plates, brackets, chute like reflux devices, sliding surface, roller, etc.
2. Food Machinery: Guard rail, star wheels, guide gear, roller wheels, bearing lining tile, etc.
3. Paper-making machine: Water lid plate, deflector plate, wiper plate, hydrofoils.
4. Chemical Engineering: Corrosion and wear-resistant mechanical parts
5. Other: Agricultural machinery, ship parts, electroplating industry, extreme low temperature mechanical components.

6.  Thermal power: coal handling, storage of coal, coal bunker lining

7.  Coal processing: sieve plate, filter, U-underground coal chute

8.  Concrete: cement raw and finished product silo silo lining

9.  Grain: food storage or chute lining

10.  Mining: sieve plate, chute linings, wearproof anti-bonding part

11. Some kind of rubber fender panels and front face of rubber fender

12. Other fields include Ice rink,water tank etc
