Home > Products > Packaging related machinery series > XFY-TXP Multi-functional Bottle Washing Sterilizing Machine
XFY-TXP Multi-functional Bottle Washing Sterilizing Machine
- Shanghai China

You May Like
Product Details
| Condition | New | Application | Beverage, Chemical, Commodity, Food, Other, Medical, Other, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Other | |
| Packaging Type | Bottles, Cartons, Film, Pouch, Stand-up Pouch | Packaging Material | Glass, Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V/380V/customized | Power | 2 KW | |
| Place of Origin | Shanghai, China | Brand Name | XINGFEIPACK | |
| Model Number | XFY-TXP | Dimension(L*W*H) | 2400x1500x1500mm | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
XFY-TXP Multi-functional Bottle washing machine
Internation:
Multi-functional bottle washing machine is used for washing glass bottle with special-shape or round bottle. Adopt the new technology of parallel bottle folder to convey the bottle and the distance of chain belt can be adjustable, so the machine has the advantage of adaptability and reliability; Each bottle can be washed by multi-channel recycle water, pure water and purification compression air, up to ideal cleaning effect.
This machine has the advantage of smooth operation, easy maintenance, cleansing effect, and equips with water vapor dealing system.
Technical parameter:
Capacity: 60~120 B/M
Range of bottles: 50~600ml
Flowing of recycle water: 0.5~1m3/h pressure:0.2~0.3MPa
Consumption of purification water: 0.5~0.6m3/h pressure:0.2~0.3MPa
Consumption of compressed air: 0.6m3/min pressure:0.2~0.3MPa
Power supply: 380v, 50Hz, three-phase four-wire system
Power: 2Kw
Dimension: 2400×1500×1500mm
Picture of the machine:
Packaging & Transportation:
Outer package: standard exported wooden case or according to customers’ requirement.
Inner package: stretch film
Transport by ship, by plane or by land.
XINGFEIPACK
------ One Brand Made in China and Moving Towards the World
Shanghai Xingfei Packaging Machinery Co., Ltd. is a professional manufacturer engaged in the research and development of packaging machinery and food machinery, and we are a member of the Chinese Food and Packaging Machinery Industrial Association.
Contact Us
                - Shanghai Xingfei Packaging Machinery Co., Ltd.
 - Contact nameLisa Gu Chat Now
 - Phone86-21-51082958
 - AddressNo. 55, Lane 835
