XFY-TXP Multi-functional Bottle Washing Sterilizing Machine

XFY-TXP Multi-functional Bottle washing machine

Internation:

Multi-functional bottle washing machine is used for washing glass bottle with special-shape or round bottle. Adopt the new technology of parallel bottle folder to convey the bottle and the distance of chain belt can be adjustable, so the machine has the advantage of adaptability and reliability; Each bottle can be washed by multi-channel recycle water, pure water and purification compression air, up to ideal cleaning effect.

This machine has the advantage of smooth operation, easy maintenance, cleansing effect, and equips with water vapor dealing system.

Technical parameter:

Capacity: 60~120 B/M

Range of bottles: 50~600ml
Flowing of recycle water: 0.5~1m3/h pressure:0.2~0.3MPa
Consumption of purification water: 0.5~0.6m3/h pressure:0.2~0.3MPa
Consumption of compressed air: 0.6m3/min pressure:0.2~0.3MPa
Power supply: 380v, 50Hz, three-phase four-wire system
Power: 2Kw
Dimension: 2400×1500×1500mm

Picture of the machine:

Packaging & Transportation:

Outer package: standard exported wooden case or according to customers’ requirement.

Inner package: stretch film

Transport by ship, by plane or by land.
