XD935G 1.6Ton grain wheel loader with CE MADE IN CHINA FOR dumping cotton seed and corn express
- 300 Unit / Units per Month
- Qingdao or other main ports as your demands
- T/T
You May Like
Product Details
Type | cotton loader | Use | farm machinery | |
Certification | CE | Place of Origin | Shandong, China | |
Brand Name | XIANDAI | Model Number | XD935G 4500mm high cotton | |
Condition | New | After-sales Service Provided | Overseas third-party support available |
1units/40HC container
Product Description
Specifications
1.1.6 ton loader for cotton or corn2. 4.5m high dump with Engine:YUCHAI
3.A/C,Joystick,Rops&Fops
4.CE certificate
XD935G 1.6 ton Grass Grab Suger Cane Loader loader
I.Basic Equipment
1.China top brand YUCHAI engine
2. Hydraulic transmission and hydraulic steering
3. China top brand SHANTUI Countershaft power-shift gearbox ,torque converter
4.Air over hydraulic break system ,caliper break system
5.Wheel reduction axle, automatic bucket flat
6.Over load protection system
7.Fan, Luxury Bumping bag spring seat, 17.5-25 low-pressure, wide-base tires
8.CE certification
9.Optional: LOVOL PERKINS engine(Europe IIIA&EPA Tire III)
II.Specifications
Description | Specification | Unit |
Bucket capacity | 1.7/2.2 | m3 |
Rated load | 1.6 | t |
Weight | 10 | t |
Overall dimension(L*W*H) | 7140*2420*3120 | mm |
Wheel base | 2600 | mm |
Wheel tread | 1800 | mm |
Min ground clearance | 400 | mm |
Main Performance Specification | ||
Dumping height | 3260 | mm |
Dumping reach | 1180 | mm |
Digging depth | 218 | mm |
Dumping angel at any position | 450 |
|
Max break out force | 120 | KN |
Max draw force | 75 | KN |
Lifting time of arms | ≤6 | s |
Lowering time of arms | ≤3.5 | s |
Dumping time of bucket | ≤1.5 | s |
Min turning radius (outside of rear wheel) | 5100 | mm |
Traveling speed | 0-35 | Km/h |
Pivot angle frame | 450±10 |
|
Oscillating angle of rear axle | ±120 |
|
Diesel engine | ||
Model | YUCHAI | |
Type | Four stroke, watering Cooling, turbo-charge engine | |
Rated power | 92 | kw |
Rated speed | 2200 | r/min |
Rated consumption | ≤280 | g/kwh |
Engine oil consumption | ≤270 | g/kwh |
Max torque | 460/1500-1700 N·m/(r/min) | |
Fuel oil tank | 160 | L |
Engine lubricating oil | 17 | L |
Starting type | Electric start | |
Net weight | 520 | kg |
Transmission System | ||
Torque converter | China top brand SHANTUI 3 elements, single stage | |
Torque ratio | 3.82 | |
Cooling type | Pressure oil circulating | |
Gear box | China top brand SHANTUI Countershaft power-shift | |
Gear shift position | Forward 4, Reverse 2 | |
Displacement of gear shift pump | 32 | ml/r |
Oil for converter and gear box | 35 | L |
Axle | China top brand YUNYU Hub reduction axle | |
Oil for driving axle | 34 | L |
Brake system | ||
Type | Air over hydraulic brake system, caliper disc brakes | |
Brake pressure | 784-833 | Kpa |
V. Payment terms & Delivery time &Guarantee time
1.Payment Terms:By TT. 30% deposit paid in advance, 70% balance paid before goods dispatching from the factory;
2.Delivery Time:within 20 days after receiving deposit;
3.Guarantee Time:one year or 1500 working hours which comes first after the date of B/L;
4.Shipping : 1 unit one 40HQ container;
