370.20.1004.030 Type 90 S/1200.12 Slew Bearing
- Main ports in China
- T/T L/C Credit Card PayPal
You May Like
-
370.20.1004.010 Type 90 S/1200 Slewing Turntable
-
370.20.0904.010 Type 90 S/1100 Turntable Bearing
-
370.20.0804.010 Type 90 S/1000 Vehicle Turntable Bearing
-
360.22.1155.010 Type 90/1300.22 WA Turntable Bearing
-
360.24.1055.010 Type 90/1200.24 WA Slewing Bearing Turntable
-
360.22.1055.010 Type 90/1200.22 WA Turntable Bearing
Product Details
| Parts | Trailer Suspension | Max Payload | 200KN | |
| Place of Origin | Liaoning, China | Brand Name | RTR | |
| Model Number | 370.20.1004.030 Type 90 S/1200.12 |
Product Description
Specifications
Rothe Erde Turntable370.20.1004.030 Type 90 S/1200.121.Warranty:12 months
2.OEM
3.Sample available
4.Technical support
1. Rothe Erde Turntable 370.20.1004.030 Type 90 S/1200.12 : Below please find the reference number of trailer turntables, and click the number to see more details and specifications.
| Number · Type | DL mm | weight kg | Da mm | Di mm | H mm | La mm | Li mm | B mm | n1 | Da1 mm | U mm | d mm | 2 axles kN | more than 2 axles kN | axial clearance mm | radial clearance mm |
| 370.20.0804.010 Type 90 S/1000 | 880/ 870 | 82 | 1000 | 834 | 90 | 966 | 952 | 18 | 6 | 987 | 871 | 20/16 | 160 | 160 | 1 | 0.7 |
| 370.20.0904.010 Type 90 S/1100 | 988/ 978 | 92 | 1108 | 942 | 90 | 1074 | 1060 | 18 | 6 | 1095 | 979 | 20/16 | 200 | 200 | 1 | 0.7 |
| 370.20.1004.010 Type 90 S/1200 | 1088/1078 | 101 | 1208 | 1042 | 90 | 1174 | 1160 | 18 | 6 | 1195 | 1079 | 20/16 | 200 | 200 | 1 | 0.7 |
| 370.20.1004.030 Type 90 S/1200.12 | 1088/1078 | 101 | 1208 | 1042 | 90 | 1174 | 1160 | 18 | 6 | 1195 | 1079 | 20/16 | 200 | 200 | 1 | 0.7 |
| 370.24.1004.010 Type 90 S/1200 SP | 1087/1078 | 101 | 1208 | 1042 | 90 | 1174 | 1160 | 18 | 6 | 1195 | 1079 | 24/16 | 300 | 300 | 1 | 0.7 |
2. RTR Trailer Turntables Applications: RTR turntables are widely used in trailers, semi-trailers, platform truck,trucks and agricultural vehicles.
3. RTR Trailer Turntables Packaging: turntables are packaged well then put on the tray.
4. RTR Group: RTR bearings, RTR slewing rings, RTR precision bearings, RTR transmission,RTR machinery, RTR engineering and RTR online bearings store make up RTR Group.
5. Market Distribution& Customer Reference: customers are spreaded all over the world and annual turnover kept increasing in past 5 years.
6.Contact Us:
