Home > Products > TVI Camera > WDR 120db Starlight 2Mpixes 2.8-12mm IR 80M TVI Camera 8X Digital Zoom Surveillance IR CCTV Bullet Camera
WDR 120db Starlight 2Mpixes 2.8-12mm IR 80M TVI Camera 8X Digital Zoom Surveillance IR CCTV Bullet Camera
- Shenzhen
You May Like
-
120dB Starlight & WDR TVI 1080P Sony 290 2MP 4.0mm Fixed Lens Night Vision Bullet TVI CCTV Security Camera
-
Starlight & WDR 1080P TVI Sony 290 TVI&CVBS Output , 8X Digital Zoom TVI CCTV Camera Quality Choice
-
Wholesale Low Price 2.0MP HD TVI Color Outside Adjust Varifocal IR Bullet CCTV Camera
-
2016 Outdoor 2.0MP HD TVI Sony 322 COMS Color IR Bullet Tvi CCTV Camera With OSD Menu
-
Full HD Fixed Lens 1080P TVI 2.0MP Color IR Bullet CCTV Camera With Sony 322 Cmos Metal Housing
-
Vari Focal Lens TVI CCTV Camera 2.0MP IR 120m Bullet Camera With OSD Menu Control Over Coaxial Cable
Product Details
| Place of Origin | Guangdong, China | Brand Name | AST | |
| Model Number | ASHT70-B36-290 | Type | Other, TVI | |
| Style | Bullet Camera | Sensor | CMOS | |
| Technology | Infrared | Special Features | Waterproof / Weatherproof |
Product Description
Full HD resolution 1920 x 1080P, outside adjust varifocal AHD IR Dome Camera, 2.8-12mm lens with IP66
Camera:
Full HD resolution 1920 x 1080P with Sony IMX290 CMOS sensor,Easy installation, HD video, OSD menu control over coaxial cable,
Starlight function, WDR , 8X digital zoom
Key Features:
1.Adopt Analog HD technology
2.Full HD 1080P TVI video output
3.1/2.8" 2.1MP Progressive Scan CMOS
4.Min illumination color 0.01 Lux
5.Day/Night(ICR)& 3D DNR&AWB&AGC&BLC
6.Support the OSD menu control
7.2.8-12mm Vari Focal Lens
8.72pcs Ø5 LEDs, up to 80m IR distance
9.Metal housing, support IP66
| Form parameters | ||
| Mode | Name and Description | TVI High Definition IR Bullet Camera |
| ASHT70-B36-290 | ||
| Camera | Media Processor | IMX322 + NVP2440H+TP2801 |
| Image Sensor | 1/2.8" 2.1MP Progressive Scan CMOS (SONY IMX322) | |
| Effective Pixels | 1984(H)*1105(V) | |
| Video Frame Rate | 1080p@25fps (PAL)/1080p@30fps(NTSC) | |
| Signal System | PAL/NTSC | |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR | |
| Shutter Time | AUTO, 1/30s~1/50,000s | |
| Lens | 2.8-12mm Vari Focal Lens | |
| Lens Mount | Ø14 Mount | |
| Day& Night | Auto,dual IR-cut filter,WDR & Starlight | |
| IR Distance | 72pcs Ø5 LEDs, up to 80m IR distance | |
| S/N Ratio | >60 dB | |
| Video Output | 1 channel, HDTVI / AHD 1920×1080P , CVBS | |
| Synchronization | Internal Synchronization | |
| Menu | Auto Gain | Low/Middle/High/Off |
| White Balance | AWB/ATW/Indoor/Outdoor/Manual | |
| D-WDR | D- WDR | |
| Noise Reduction | 2D/3D DNR | |
| Private Mask | On/Off, maximum 8 zones | |
| Motion Detection | On/Off, maximum 4 zones | |
| Language | Chinese/English/German/French/Italian/Spanish/polish/Russian/Portuguese/Turkish | |
| Function | AWB, AGC, BLC, HLC , Mirror, Motion Detection | |
| General Parameters | Power Supply | DC12V |
| Operation Temperature | -20℃ - +50℃ | |
| Operation Humidity | Less than 95%RH(no condensation) | |
| Weather Proof Rating | IP66 | |
| Installation | Equipped With Bracket | |
| Dimension | 295*87*87mm | |
| Weight | 0.93KG | |
1. About the sample: How could I get a sample?
Once receive your payment for samples and their express delivery and then send samples
to you. The prices of the samples are the same as those on the pricelist. Express delivery
charge depends on the quantity of the samples.
2. About price list: can I get your price list?
Yes, please tell us the products (with their code number) and order quantity, then we will
offer the price by e-mail. And our price list will keep updated every month.
3. About the shipment: what type of shipment will you use?
We usually ship the products by express delivery to your door or by air freight to your nearest
airport. If the order quantity is large, we may ship by sea container.
4. About payment: what terms of payment do you use?
We accept TT (Telegraphic Transfer,MoneyGramor Western Union as payment term for small
order and L/C for larger order.
5. About the MOQ: What is your minimum order qty?
Our minimum order qty is 20pcs each model, but we accept small order as trial order.
6,About compensation: what is your company's compensation policy?
We can compensate buyer's loss if our products have quality problem. For small qty
problem products, we can replace with new products in next order. For larger qty problem
products, we can accept returned problematic products, then we check them and replace
them by good quality products.
7. About sole-distributor: How can I be your sole-distributor?
We have special policy for sole-distributor. Please contact our sales person to get related files.
8. About OEM: could we place order by OEM style to produce our own brand products in China?
Of course you can. Welcome to do OEM.
If any further problem, welcome to contact our sales person.
Thanks for your interest
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery Time:
Sample order 3-5 working days, bulk order 7-15 working days.
Quality Warranty:
2 years for free repair. Whole life service for continue cooperating customers!
Price Term:
EXW Shenzhen
Delivery Term:
By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST),By air,By Sea.
