Wood Pallet Maker , Wood Pallet Foot Extruder , Wooden Pallet Block Hydraulic Extruding Machine
- Qingdao/Tianjin/Shanghai/Any China Mainland Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Wood Sawdust Block Making Machine , Solid Wooden Pallet Block Hot Press Extruding Machine
-
Wood Chips Pallet Block Extruding Machine / Wooden Pallet Log Making Machine
-
Wooden Pallet Log Extrude Machine / Wooden Pallet Blocks Making Machine / Machine to Make Pallet Block
-
Wood Shaving Pallet Feet Hot Pressing Machine / Wood Waste Hydraulic Hot Press Extruding Machine
-
Single and Double Heads Wooden Pallet Leg Hot Press Machine / Wood Sawdust Pallet Block Forming Machine
-
Wooden Pallet Leg Press Machine / Wooden Pallet Block Compressed Machine Supplier's Choice
Product Details
| Condition | New | Type | Hot Press | |
| Application | Pallet Feet Block Making | Pressure | 5Mpa | |
| Place of Origin | Henan, China | Brand Name | Pasen | |
| Model Number | PS | Voltage | 380V or customised | |
| Power(W) | 14.6kw | Dimension(L*W*H) | 8000*700*1500mm | |
| Weight | 1000kg | Certification | BV | |
| Warranty | 24 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Wood Sawdust Block Making Machine, Wood Pallet Feet Block Making Machine, Wooden Pallet Block Making Machine, Compressed Wood Blocks Making Machines
Introduction of Compressed Wood Blocks Making Machines
It is used to turn the wood waste such as sawdust, wood wools into the pallet feet which is for the transportation pallet. The final product could get the E1 grade.
The pallet feet could be solid without hole in the center, also could be hollow.
Besides, you could customise the mold for other shape wood waste compressed products.
Block sizes could be customised from 75mm to 145mm. And the usual sizes are90*90mm, 90*100mm, 100*100mm,80*90mm.
Work flow of Compressed Wood Blocks Making Machines
a, Crushing the wood, branch, wood waste into sawdust, wood shavings or wood wools (or you have the raw material already);
b, Drying the raw material to 8% (solid block) or 10%(hollow block);
c, Mixing the raw material with glue;
d, Pressing them in the wood pallet block machine;
e, First cutting the product from pallet block machine into bar;
f, Second cutting the strip into the single blocks.
Parameters of Compressed Wood Blocks Making Machines
Model | PSST(Double Heads) | PSDT(Single Head) |
Specification of blocks | Length: 75-145mm Width: 75-145mm | |
Power | 22.26kw | 14.66kw |
Density | 500-800kg/m3 | |
Capacity | 4m3/24h | 2 m3/24h |
Warm prosecution type | PID adjusts the merit accent to press the control | |
Voltage | 380V 50HZ 3-phase (could customise) | |
Weight | 1500kg | 1000Kg |
Dimension with manual saws | 8000*700*1300mm | 8000*600*1300mm |
Photos of Compressed Wood Blocks Making Machines
Delivery Time | Within 7-15 working days after receiving clients’ payment. |
Payment Terms | T/T, L/C, D/P, D/A, Escrow, Paypal, Western Union |
Packing | a. Machines are wrapped in plastic film first before packing, which is to avoid moisture on the sea. |
Quality Guarantee Terms | Quality guarantee term is for one year. Malfunctions which are caused by machineself and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self. |
Service | All produts purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. a, Before sending the machine, we will test and adjust, so you can use directly when you get it. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will solve your problems in time. If you are caught in some problems when using our products, welcome to contact us at any time. a, Any problems occur while using, professional advice will be offered. |
--- Why Choose Us
1.We are Wood Pallet Feet Block Making Machine Manufacturer.
2.Alibaba Assessed Gold Supplier.
3.Inspected by the Inspection Institution of Bureau Veritas Certification.
4.100% QC inspection Before Shipmeng.
5.Best Quality & Service with Competitive price
1, Are you manufacturer?
Yes, we are manufacturer with more than 15 years' experience.
2, Can you ship the machine to my place?
Yes, we could ship the machine to your nearest sea port and your agent could pick it up there and arrange the land transportation. It can not be shipped by air because of its big size.
3, Where are you? Can we go to China and visit your factory?
Yes, of course. We are in Henan, China. Welcome to our factory. We will pick you up at the airport.
4, Do you have manual with the machine?
Yes, of course. It is in English version.
5, Can you offer us the necessary paper to do the customs clearance?
Yes, of course. We will send you the commercial invoice, sales contract, packing list, bill of lading(FOB or CFR, CIF terms), insurance policy (if CIF terms), also CO if you need.
