High Precision Pressure Sensor
- XI'AN
- T/T Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | HT | |
| Model Number | HT20V |
Product Description
Specifications
Isolated pressure sensorConstant voltage supply
Description
HT20V isolated diaphram differential pressure sensor is constant voltage supply, utilizing the piezoresistance
effect of diffused silicon to fulfill measuring and controlling pressure of liquids & gases. It has high credibility, repeatability and stability.
Feature
Isolated pressure sensor
Full 316L stainless steel
High accuracy and high stability
Application
Measure of gases & liquids
Pressure measuring instrument
Measure differential pressure
Process control
Electrical Data
Supply: 10VDC Input Impedance:6KΩ~20KΩ
Output Impedance:2.5KΩ~6KΩ Insulation Resistance:≥100MΩ/50VDC
Insulation Voltage:500VAC between the case and electrical connections will not cause damage
Medium Compatible: Liquid, gases which compatible with 316LSS
Performance Specification
Dimension
Electrical Connection and Circuitous Philosophy
