4-20ma Air Differential Pressure Transmitter
- XI'AN
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | HT | |
| Model Number | BP93420DI |
Product Description
Specifications
used to measurement dry gas pressureSpecification
Range | Ⅱ: 0~500Pa…..2000Kpa |
Medium | Ⅱ: Dry gases compatible with Aluminium casting or plastic |
Proof pressure | 1.5X rated range or 7MPa(Which ever is less) |
Accuracy | ±0.5% |
Static pressure | 5X rated range |
Long term stability | ±0.2%F.S/year |
Zero temperature Drift | ±1%F.S(typical) ±1.5%F.S (Max.) |
Span temperature Drift | ±1%F.S(typical) ±1.5%F.S (Max.) |
Operating temperature range | -20°C~80°C |
Storage temperature range | -40°C~120°C |
Power supply | 15~36VDC |
Output signal | Ⅱ:4~20mA |
Pressure port | diameter 6 air cock or customize |
Housing material | aluminium casting or plastic |
Cable | Polyethylene ventilate cable |
Insulation resistance | 100MΩ,100VDC |
Protection | IP65 |
