Hot Sale Intel Atom Dual Core CPU D525 MINI ITX Mainboard All In One Motherboard

Specifications

Hot Sale Intel Atom Dual Core CPU D525 MINI ITX Mainboard Intel Atom Mainboard

Introduction:

INTEL D510 - D525 + NM10 series chipset,

Support INTEL EBGA437 533 external clock ATOM D510 - D525

Support: dual channel DDR3 memory.

Plate load: Intel GMA 3150 graphics core.

Support: a PCI.

Provide: 2 COM port, and 2 IDE interface, 2 SATA interface,

support: ALC662 channel output, a Realtek 8103 c, 10/100/1000 m Ethernet controlle

Specification

MINI-ITX Embeded Motherboard Specification

-ITX

Layout Diagram

Jumper

Connectors

Headers

Hardware Installation

Jumper Setting

(1) Clear CMOS (2-pin): JBAT

(2) Serial-ATAII Port connector: SATA1/SATA2

(3) Large 4-Pin Power Connector: PWR1
The connectors are 4-pin connector that supports extra 12V / 5V power to your
system.

Headers

(1) Line-Out, MIC-In Header (9-pin): FP_AUDIO1 Header
This header connects to Front Panel Line-out, MIC-In connector with cable.

(2) CD AUDIO-In Headers (4-pin): CDIN1
CDIN are the connectors for CD-Audio Input signal. Please connect it to CD-ROM
CD-Audio output connector.

(3) Serial Port Connectors (9-Pin female): COM1

(4) USB Port Headers (9-pin): USB3

(5) USB Port Headers (4-pin): USB2

(6) Front Panel Header: FP1

(7)FAN Speed Headers (3-pin): CPUFAN1, SYSFAN1
Pin1: GND
Pin2: +12V fan power
Pin3: Fan Speed

(8) GPIO Header (10-pin): GPIO_CON
