Product Details
| Condition | New | Type | Rotary Drilling Rig | |
| Power Type | Diesel | Place of Origin | Henan, China | |
| Brand Name | HANFA | Model Number | HF80 | |
| Usage | Water Well | Power(W) | 11kw | |
| Dimension(L*W*H) | 1.6m³ for full package | Weight | 500kgs for full package | |
| Certification | CE, BV, SGS | Warranty | 1year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HF80 Portable and Economical Water Borehole Drill Machine
I. Application
This machine mainly used for farm irrigation and water well drilling, drilling diameter is 70-300mm, and drilling depth is 60-80m.
It also can be used in small building piling, like farmhouse or factory and so on, the drilling diameter can reach 500mm and depth can be more than 10m.
II. Features and Advantages
1. Light weight. The main engine is only weighted 135kg.
2. Easy to operate. It can be handled by 1 to 2 persons with a minimal skill level.
3. Durable. The first generation of products used for 13 years, drilled more than 4000 water wells, nearly no repair record except the drilling bits.
4. Suitable for soil and not very hard rocks, such as gravel, cobble, weathered granite and redbrick. It is mainly used on plains.
5. Can drill deep. Equipped with raiser, reduce the labor intensity.
6. High efficiency, the drilling speed can reach 20meters depth per hour, in plain area.
III. Technical parameter
Drilling depth | 60-80m |
Drilling diameter | 70-300mm |
Power Engine | 15HP(11kw) |
Dimension(LXWXH) | 1100X600X500mm |
Weight | 0.135 t |
Our certificate
On exhibition
