20 - 0mA Magnetostrictive Level Sensor

FOB Price

US$ 200 - 700 / Piece

1 Piece(Min. Order)

Port Hong Kong
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Germany	Brand Name	Germanjet
Model Number	17 Series	Usage	Position Sensor
Theory	Other, Magnetostrictive	Output	Analog Sensor

Product Description

Magnetostrictive Position Sensor, Level Sensor

17 Series - Hydraulic Cylinder Insert

The 17 series non-contact absolute position transducer is specially designed for hydraulic cylinder to provide precise, direct and absolute position feedback. Hydraulic body is made by stainless steel; it can be inserted directly into hydraulic cylinder. Electronic component and hydraulic body are modular design which can be detached easily.

The transducer is rated for IP65 which offers full protection against outside agents for use in harsh environments with high contamination and presence of dust. The connector is common for use in hydraulic device and easy for field connection. Besides for hydraulic system, it is also suitable for machine installation. The absence of electrical contact eliminates all wear and guarantees almost unlimited mechanical life expectancy.

Order Code	172
Output	20 - 0mA
Measurement Type	Linear displacement
Resolution	Infinite, restricted by output ripple
Input Voltage	+24Vdc (20.4 - 28.8Vdc)
Input Protection	Polarity protection up to -30Vdc, Over voltage protection up to 36Vdc
Current Consumption	50-140mA (stroke range dependent)
Dielectric Strength	500Vdc (DC ground to machine ground)
Repeatability	< ±0.005% of full scale
Non-Linearity	< ±0.02% of full scale (minimum ±90 μm)
Update Time	0.5 ms up to 1200 mm / 1.0 ms up to 2500 mm
Operation Temp.	-40 to 75 °C, Humility 90% non-condensing
Sealing	IP65 (with 4 pin connector) / IP67 (with D60 and M12 connectors)
Vibration Rating	15g / 10-2000Hz / IEC standard 68-2-6
Shock Rating	100g single hit per IEC standard 68-2-27
EMC	Emission EN 68000-6-3, Immunity EN 61000-6-2, EN 61000-4-2/3/4/6
Pressure Rating	350 bar / 600 bar peak
Mounting	M18 x 1.5
Housing Materia	Anodized aluminum cartridge, Stainless steel tube and flange, Plastic cartridge cover
