Home > Products > DTH Drilling Rig > Quality ensure!!New type!!HF138Y crawler type high pressure DTH drilling rig

Quality ensure!!New type!!HF138Y crawler type high pressure DTH drilling rig

FOB Price

USD $20,000 - $100,000 / Set

1 Set(Min. Order)

Port Qingdao Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other
Power Type	Diesel	Place of Origin	Henan, China
Brand Name	HF crawler type DTH drilling rig	Model Number	HF138Y crawler type DTH drilling rig
Usage	Water Well	Voltage	220V/380V
Power(W)	45kw	Dimension(LWH)	520020302300mm
Weight	3800kgs	Certification	CE certificate
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

HF138Y crawler type high pressure DTH drilling rig

1. Application of HF series water well/core drilling rig
Since our establishment in 2004, we have been devoting ourselves to researching and developing easy-operation, highly-efficient and large-capacity drilling rigs.

2. technical parameters about this drilling rig

HF138Y type crawler hydraulic drilling rig, using a new hydraulic technology, with low air consumption rotary

torque, variable-bit-shift hole easy The drilling rig compact structure, while promoting a retractable sliding shelf

compensation, drilling when the sliding frame support on the ground, drilling and good stability.

Use 138Y rig reliable Chazzan efficient drilling in hard rock drilling rig as fast as 2 times the low

air pressure is the construction unit cost efficiency gains strong support.

The drilling rig is mainly suitable for open mining, water conservancy, power plants, road buildingand other

Rock blasting whole drilling.

Main technical parameters of HF138Y
Wind pressure (Mpa)	0.7----1.6
Air consumption (m³/min)	10----15
Drilling diameter (mm)	90----130((max:203)
Drilling depth (m)	level 40m,down 80m
Once promotion distance (mm)	3000
Drill diameter (mm)	60
Skid compensation (mm)	900
Maximum lift force (N)	24900
Skid pitch (°)	up and down total 95
Swinging angle of skid (°)	Left 38, right 31
Boom Pitch (°)	up and down total 70
Boom swing angle (°)	Left 41, right 33
Grade ability (°)	30
Chassis ground clearance (mm)	260
Travelling speed (km/h)	2
Back to the transit speed (r/min)	0----80
Rotary torque (N.m)	2000
Host Power (Kw)	45
For rock (f)	6----20
Impact frequency (r/min)	950---1500
Total Weight (kg)	3800
Dimension (L * W * H)	520020302300

Note: The Company’s products continued to improve; various design and technical specifications

may change at any time, without any additional notice or obligation.
