Full Hydraulic System!Best Sell!HFDX-6 Full Hydraulic Crawler Type Core Drilling Equipment
- Qingdao Tianjin or Shanghai
You May Like
-
Hydraulic,700-1000m Depth,can Drill Hard Rock!!! HF-4T Tower Mounted Practical Core Drilling Rig
-
Full Hydraulic System!Best Sell!HFDX-6 Full Hydraulic Crawler Type Core Drilling Rig
-
Hydraulic,700-1000m Depth,can Drill Hard Rock!!! HF-4T Practical Core Drilling Rig
-
Easy Operate!Most Economic!HF-4T Tower Mounted Most Economic Core Drilling Rig
-
For Exploration and Survey HFR-8 Full Hydraulic Wireline Core Drilling Rig
-
Quite Popular in the Market HFU-3A Underground Portable Core Drilling Rig
Product Details
| Condition | New | Type | Core Drilling Rig | |
| Power Type | Diesel | Place of Origin | Henan, China | |
| Brand Name | HanFa multi-function drilling machine | Model Number | HFDX-6 multi-function drilling machine | |
| Usage | Water Well | Voltage | 220V/380V | |
| Power(W) | 178kW | Certification | ISO CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HFDX-6 full hydraulic crawler type core drilling equipment
I. General Introduction
HFDX-6 Hydraulic Core Drilling Rig,an up-to-date new product,is a thoroughly new-typed drilling rig developed on the basis of the advanced techniques in the world.
1. Main Features of the rig:
1)Reliable Quality
2) High Efficiency
3) Environmental Protection
4) Energy Saving
2. Application Range
HFDX-6 can be applied to both slant and vertical drilling. Being a rig equipped with diamond and the carbide alloy bit drilling, it can be used in the fields of geology, metallurgy, coal mining, nuke industry and hydrology measuring.
II. Main Performance Parameters of HFDX-6
The figures in these tables have been calculated, based on field experiences, and may be reasonably expected.
Actual drilling capacity will depend on in-hold tools and conditions, drilling techniques and equipment used.
Diesel Engine | Model |
Cummins 6CTA (turbocharged and charge water cooled) |
Displacement | 8.3L (2.19 US Gallons) | |
Power | 178kW (240HP) | |
Rated RPM(Factory setting) | 2200rpm | |
Drilling Capacity | BQ | 2000 m(6560 feet) |
NQ | 1600 m(5248 feet) | |
HQ | 1300 m(4264 feet) | |
PQ | 1000 m(3280 feet) | |
Drill Head | Rotation Motor | Double Hydraulic Motor
-variable and Reversible
Maker: SAUER-DANFOSS |
RPM |
Two Shifts/ Stepless Change 0-1100 RPM | |
Ratios | 1st 8.776:1 2nd 2.716:1 | |
Head Opener | sidewise sliding way with hydraulic drive | |
Hydraulic Chuck(PQ) |
Hydraulically opened, Disc Spring Clamping, Normally C Closed Type Axial Holding Capacity of 222 400 N | |
Max. Torque | 6400 N.m(4717 lbf.ft) | |
Hold Diameter | 121 mm(4.76 inch) | |
Max. Lifting capacity of Spindle | 220 kN(49456 lbf) | |
Max. Feeding Power | 110 kN(24728 lbf) |
