AJ-P300G High-quality Easy Operation Mature Technology Infusion Pump

Product name

AJ-P300G

Unique Voice Alarm system

The device triggered the voice prompt and stop injection automatically when there is any malfunction, making the infusion process safer and more reliable.

Infusion rate

1ml/h~1,200ml/h

Purge rate

100ml/h~1,200ml/h (100 ml/h increment)

KVO rate

1ml/h~5 ml/h (1ml/h increment)

Accuracy

Within ±5% (after correct calibration)

Infusion Volume

1ml~9999ml

Total Infusion Volume

0.1ml~9999.9ml

Occlusion detection pressure

High: 800±200 mmHg (106.7±26.7 kPa)

Medium: 500±100 mmHg (66.7±13.3 kPa)

Low: 300±100 mmHg (40.7±13.3 kPa)

Bubble detector

Ultrasonic wave detector; detection sensitivity ≥25μL

Alarms

End of injection, occlusion, door open, bubbles in the tube, wrong setting, low battery, AC power pulled out etc.

Power

AC100V~240V, 50/60Hz; Internal rechargeable Li battery, capacity≥1,600mAh, 4 hours internal battery backup

Operation conditions

Ambient temperature: +5°C~+40°C;

Relative humidity: 20~90%

Atmospheric pressure: 86.0kpa~106.0kpa

Storage conditions

Ambient temperature: -30°C~+55°C

Relative humidity: ≤95%

Equipment Classification

Class II, internal power supply, Type BF

IP grade

IPX1

Dimension

140mm (L) × 157mm (W) × 220mm (H)

Weight

1.8kg (net weight)
