Home > Products > ductile iron pipe > Tyton Joint Ductile Iron Pipe
Tyton Joint Ductile Iron Pipe
- china main ports
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanxi, China | Brand Name | allwin | |
| Model Number | DN80-DN1600mm | Length | 6m/5.7m | |
| Standard | ISO2531 EN545 | Application | WATER | |
| Diameter | dn80-dn1600 | |||
| Hardness | 230 | Pipe Wall Thickness | k9 | |
| Pull Strength | 420 | |||
| Type | Other, socket, socket plain |
Product Description
Specifications
ductile cast iron pipe-ISO2531/EN5451.range dn80-dn1600mm
ply with ISO2531 and EN545
3.T- type
centrifugal casting ductile iron pipes according to ISO2531 and EN545
Material:Ductile iron
(1) standed:ISO2531-1998,EN545-2006,Class:K8,K9
(2) Effective length:6M by
(3) Inner surface cement linning according to ISO4179 and outer surface bitumen lining according to ISO8179
(4) Zinc casting:at least 130g/m2 as per ISO8179
(5) DN80-DN1600mm
(6) T-type
(7) High strength ,lighter than gray iron,good corrosion resistance,no furring,small flow resistance,easy fixing,long life time
(8)Gasket: 100% SBR/NBR/EPDM rubber gasket in accordance with ISO4633.
(9)Packing: Pipes from DN100 to DN300 be bundled with steel belts, others are in bulk ship,5.7M by 20' or 40' containers.
(10)Payment term: L/C, T/T.
