High Capacity Gravity Concentrate Processing Gold Jig Separator

Model

Chamber

Feeding Size(mm)

Water added
(m3 /T)

Pressure of water
(Mpa)

Processing capacity
(t/h)

Motor Power
(t/h)

Dimension
(mm)

Weight
Kg

shape

Area/m2

JT0.57-1

Ladder

0.57

<6

1-3

>0.5

1-2.5

1.5

1550*780*1530

610

JT1-1

Ladder

1.04

<10

1-3

2-4

2.2

2270*1110*1890

900

JT2-2

Rect

2.28

<10

1-3

4-8

3

3225*1550*2050

1640

JT3-1

Ladder

3.3

<10

1-3

>0.5

6-10

5.5

3180*2000*2600

3260

JT5-2

Ladder

4.86

<10

1-3

10-15

7.5

3600*2000*2600

4500

JT1.5-2

Rect

1.53

<30

1-2

>0.5

5-8

3

3200*1550*2050

1520

JT4-2

Rect

4.33

<30

1-2

10-15

7.5

3600*1850*2600

4600

   TYPE

STLB19

STLB30

STLB60

STLB80

STLB100

CAPACITY (T/h)

0.2-1

2-8

10-40

35-70

75-120

PARTICLE SIZE (mm)

0-3

0-4

0-6

0-6

0-6

FEEDING CONCENTRATION(%)

0-50%

0-50%

0-50%

0-50%

0-50%

BACKWASH WATER(T/h)

1.5-2

4-6

10-15

17-25

40-60

OUTPUT (KG/TIMES)

2-3

10-20

30-40

60-70

70-80

POWER (kw)

0.75

1.5

4

15

18.5

REVOLUTION (r)

800

600

460

400

360

PRESSURE WATER (Mpa)

0.04

0.12

0.4

0.4

0.6

DIMENSION (mm)

790*785*790

1180*1140*1250

1970*1670*1750

2300*1800*2200

2500*2000*2400

WEIGHT (kg)

145

400

1300

1500

2000

Model

Specification

Input size(mm)

Rotate Speed (r/min)

Powder(kw)

Weight(t)

1600A

1600×400×200×500±20mm

30mm

20-22

25KW

14.5

1500A

1500×350×200×460±20mm

20-22

22KW

13.5

1500B

1500×350×150×460±20mm

20-22

22KW

12.3

1500C

1500×300×150×420±20mm

20-22

22KW

11.3

1400A

1400×250×150×350±20mm

16-18

18.5kw

8.5

1400B

1400×250×150×350±20mm

21-23

18.5kw

8.5

1350A

1350×250×150×350±20mm

16-18

 18.5kw

8

1350B

1350×250×150×350±20mm

21-23

18.5kw

8

1300A

1300×250×150×350±20mm

16-18

15kw

7.5

1300B

1300×250×150×350±20mm

21-23

15kw

7.5

1200A

1200×200×80×250±20mm

17-19

7.5kw

5.5

1200B

1200×200×80×250±20mm

23-25

7.5kw

5.5

1100A

1100×200×80×250±20mm

17-19

7.5kw

5

1100B

1100×200×80×250±20mm

23-25

7.5kw

5

1000

1000×200×80×250±20mm

13-15

5.5kw

4.5

900

900X200X80

10-15

5.5kw

3

Model

Capacity

Power

Screen

Diameter

Screen

Length

Discharge

Size

Input Size

Dimension
(L×W×H)

Weight

(t/h)

(kw)

(mm)

(mm)

(mm)

 (mm)

 (mm)

(kg)

GTS1015

5-10

3.0

1000

1500

0~100

≤300

2600×1400×1700

2200

GTS1020

10-20

4.0

1000

2000

 3390×1400×2140

2800

GTS1225

20-50

5.5

1200

2500

 4146×1600×2680

4200

GTS1530

50-80

7.5

1500

3000

 4460×1900×2820

5100

GTS1545

80-120

11

1500

4500

 ≤400

5960×1900×3080

6000

GTS1848

100-160

15

1800

4800

6500×2350×4000

7500

GTS2055

150-250

22

2000

5500

7500×2550×4800

9600

GTS2265

200-300

30

2200

6500

8500×2750×5000

12800
