Guangzhou Electric Sliding Gate Motor With Backup Battery, Automatic Motor for the Gates

box

All our door and door opener products price 5% off during 1st June to 1st Sep, 2016.
Welcome to contact us via wechat/whatsapp: 008613760677858.

Product Key Words

sliding gate opener,

automatic gate operator,

sliding pitio door opener,

electric gate opener,

steel gate operator,

gate motors

Made in Guangzhou, China

Product Pictures

Product Description

This electromechanical reduction gear operator is designed for domestic and middle

range collective applications.

The small size allows setting it in reduced areas.

The sliding gate must be well made (rigid). It must operate smoothly when it is moved

manually on a perfectly horizontal rail.

Domestic and collective applications (400 cycles/day), weight of gate up to 600kg,

a built-in electronic control unit is included.

Function & Performance

Oil bath mechanical driving

Max gate weight 600kg

Miniaturization design (260HX220WX120L)

Quiet, durable, great pulling, frequently usage

Built-in electronic control unit

Untouched magnetic induction range limited switch

Restorable thermal protecter

Torque adjustable system

2 separated program (full open or half open)

Automatic delay closing after gate opened (delay time adjustable/cancel)

2 channels for remote control

Can be connected wired/wireless switch (1 or 3 button manual switch)

Non dialing remote control (digicoder above 100 million)

2 leaves sliding function does not need an extra controlling unit

Self learn function

When opening/closing, slowing down operation act at the end of stroke (reduce

impact, exact orientation)

Flash light or illunimunation power output, and pre-alarm light function

Opening/closing photocell input

Long life, low noise, exempt maintenance

Extending port reserved for system upgrade

Technical  Data

Max Gate Weight:                600kg

Operating Voltage:              220V , 50HZ (or other optional)

Max Power Rating:              350W

Gate Speed:                         9.5m/min

Operating Temperature:   -25°C   +70°C

Motor Speed:                       1400 rpm

Motor Weight:                      11.5kg

Carter:                                   Aluminum

Protection Range:              55

Other Products Model: 1202,1807,1908,1910,1802A (swing gate opener), 1802B

                                            (swing gate opener)

 Packaging

Other Products

We produce and sell different styles of automatic doors. Our products include,

1, automatic door opener, gate operator, access control system;

2, wrought iron gate, expansion gate, steel gate, sectional garage door, rolling

    shutter door, grill door;
3, hospital door, x-ray proof lead-lined door, clean room door;
4, aluminum glass window, glass door;
5, fire rated steel door, fire rated rolling shutter.

Our Services

Customer satisfaction is very important to us and our feedback rating reflects this

satisfaction. If you have any questions, our Customer Service staffs welcome you

to email us. We strive to answer all questions and resolve any problems as quickly

as possible.

Company Information

Our Company, Guangzhou OUYANG Security and Building Material Tech Co., Ltd.,

is one of the super automatic door manufactures in Guangzhou, China.

Established on 2002, we major in selling automatic door products.

Our products include remote garage door, aluminum rolling door, steel rolling door,

rolling grille door, electric sliding door opener, remote gate opener (sliding and swing),

swing room door opener, operating room doors, X-ray proof doors, and the related

entrance guard system.

All our automatic motors have CE Certificate. We offer excellent sale and after-sale

service. And we can produce different size doors for you.

If any need or question, please feel free to contact me via

phone: 0086 137 6067 7858 (Mr. Luan),

skype: automaticdoors1,

whatsapp/wechat: 008613760677858

or send me an email per alibaba system. You will get my reply within 12 hours.

More information, please log on our website: .

We are in Guangzhou, China. Welcome to visit our factory.
