XCMG 4t Crawler Excavator XE40

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	XCMG	Model Number	XE40
Condition	New	Moving Type	Crawler Excavator
Operating Weight	4050kg	Bucket capacity	0.14m³
Maximum Digging Height	5317mm	Maximum Digging Depth	3598
Max Digging Radius	5810	Certification	CE
After-sales Service Provided	Engineers available to service machinery overseas

mini excavator

Items	Unit	Value
Bucket capacity	m3	0.14
Operating weight	kg	4050
Standard bucket width(with/without cutting blade)	mm	652
Digging Capacity
Max. digging height	mm	5317
Max. digging force (bucket)	kN	23.2
Min. slewing radius of rear part	mm	1490
Min. slewing radius of front part (swing)	mm	2385
Max. digging radius	mm	5810
Max. vertical digging depth	mm	3330
Max. digging depth	mm	3598
Max. discharge height	mm	3697
Engine
Model		4TNV88
Rated output	kw (hp)	27.1/2200
Overall exhaust	L (ML)	2.19
Machine Size (During transportation)
Overall length	mm	5455
Min. ground clearance	mm	350
Overall width	mm	1650
Overall height	mm	2440
Undercarriage
Wheelbase	mm	1721
Gradeability	%	58
Travel speed (1st/2nd gear)	kmh	4.2/2.6
Track gauge	mm	1335
