Float Pyrex Glass/high Borosilicate Glass Sheet 3.3

float pyrex glass/high borosilicate glass sheet 3.3

 Specification

Application

Borosilicate 3.3 serves as a material of truly functional and wide application:

1).  Household electrical appliance (panel for oven and fireplace, microwave tray etc.);
2).  Environmental engineering and chemical engineering (Lining layer of repellence, autoclave of chemical reaction and safety spectacles);
3). Lighting (spotlight and protective glass for jumbo power of floodlight);
4). Power regeneration by solar energy (solar cell base plate);
5). Fine instruments (optical filter);
6). Semi-conductor technology (LCD disc, display glass);
7). Iatrology and bio-engineering;
8). Safety protection (bullet proof glass)

Specification of Product

1)Dimension: 1200mm×600mm 1200mm×900mm 1200mm×1800mm other formats upon request

2)Available thickness: 1mm--12mm

List of Thickness and Tolerance
Thickness mm  Tolerance mm

2.00 ±0.20    5.00 ±0.15
2.25 ±0.20    5.50 ±0.15
2.75 ±0.20    6.00 ±0.15
3.0 ±0.20      6.50 ±0.20
3.30 ±0.20    7.50 ±0.30
3.80 ±0.15    8.00 ±0.30

3) Net sized glass of strengthening can be supplied as per customer's requirement;
4) Glass of small cut size is available according to the requirement from customers.

Performance of the Product

1).  Mechanical Performance
Density  ρ              2.23±0.02g/cm3

2). Thermodynamic Performance

Thermal expansion coefficient           (0-300) 3.3±0.1×10-6K-1
Softening point        820±10
Strain point        516±10
Caloricity (20-100) 0.82KJ × (kg×K)-1
Thermal coefficient        1.2W×m×K-1
Thermal shock resistance 180K
Strengthening type 300K
Identical temperature difference 100K
Strengthening type 300 K
Maximum working temperature Short time(<10h): 500
Long time(>10h): 450

3).  Chemical Performance
 Water resistance                      ISO719/DIN12111 HGB1/ISO720 HGA1
 Acid resistance ISO1776/DIN12116 1
 Alkali resistance ISO695/DIN52322 A2

4). Optical Property
Refractive index Nd: 1.47384
Transmittance spectrum curve

5). Electrical Property
Specific resistance lgρ  8.0Ω×cm at 250
Dielectric dissipation fraction tan σ (1 megacycle at 20): 38×10-4
Dielectric constant ε=4.7

NOTE:The above mentioned specifications are in conformity with standard of ISO3585 after inspection and detection as well as examination by the Quality Supervision and Inspection Center of the National Light Industry for Glass Product and, Beijing Glass & Ceramic Quality Supervision and Inspection Center.

Means of Processing for Customer

 *Cutting
 *Round corner
 *Round edge
 *Surface fine polishing
 *Hole drilling
 *Coating
 *Surface printing and sand blasting
 *Thermal bending
