Home > Products > Rubber Conveyor Belt > Filter Belt Conveyor Belt Made in China

Filter Belt Conveyor Belt Made in China

FOB Price

US$ 5 - 200 / Meter

100 Meters(Min. Order)

Port Any port in China
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	Hyrubbers
Model Number	Rubber Conveyor Belt

Product Description

Filter belts are used in specialized dewatering process equipment for separating solids from liquids in a slurry. It is used in the processing of minerals, ores, chemicals, dyes, foodstuffs, coal and paper as well as in flue-gas desulfurization systems and in fertilizer production etc.
Our filter belts with fabric-free zones, these belts have the entire carcass removed from exposed areas, usually around the drainage holes and often the edges of the belt. The carcass of the belt is safely protected by a wall of solid rubber. Our filter belts are also with the properties of high-strength, low-elongation, laterally stable, good chemical resistance, high temperature stability, good aging- and sun-cracking-resistance.

Production Range:
Belt W idth : 0-3400 mm
Length: 20-200m
Total Thickness: 20-50 mm
Top Cover Rubber: 10-30mm
Bottom Cover Rubber: 5-15 mm

Rubber Qualities: Normal, Heat resistant, Acid and alkali resistant, Oil resistant.

Packaging & Shipping

Except good raw material, good production equipments and technology, the safe and user-friendly packing is also very important for sidewall belting. HYRUBBERS have been packing conveyor belt in standard way to ensure the belt is safe during transportation and storage period.

packaging:packed in rolls and covered by fabric water-proof cloth,or clients' requirement also be respected

shipping:within 10-20 days,or depends on the quantity

Company Information

HYRUBBERS CO.,LTD is specializing In manufacturing, exporting and developing conveyor belt, in the same time rubber sheet, rubber tiles and so on.

The factory founded has 260 people including 220 workers, and 15 engineers and technicians, 25international sales workers, covering an area of 50000 m2, owing 220 sets of main production equipment.

The ISO9001: 2000 certified factory has established a stable and reliable quality control system with a modem management.

Now with the export quantity larger and larger, we become one of the biggest manufacture in North of China.

Adhesion and elongation of the belt:

Belt carcass	Adhesive strength			Elongation
	Between plies N/mm	N/mm Between ruber and carcass		Longitudinal elongation at break %>=	Longitudinal elongationa at reference load %<=
		Rubber thickness <= 1.5mm	Rubber thickness > 1.5mm
EP canvas	>=4.50	>= 3.20	>=3.50	10	4.0

Cover properties of the belts:

Cover grade	Tensile strength >=		Elongation >=	Abrasion <=	Change Rate of tensile strength and elongation after aging
Cover grade	Mpa	kgf/cm²	%	mm³	%
Heavy(H)	24	240	450	120	-25~+25
Medium(M)	18	180	400	100	-25~+25
Light(L)	15	150	350	200	-30~+30

Accordance with different applications, we can produce different grades of belt as following:

1) Heat Resistant Belt

According to the temperature of working environments, we can manufacture 3 different grades heating resistant belt, including up to 120℃ grade (HR120), up to 150℃ grade (HR150), up to 180℃ grade (HR180) and up to 200℃ grade (HR200) .Generally used by cements and steel works.

2) Abrasion Resistant (≤90mm3) / super abrasion resistant (≤60mm3) Belt

Generally used for transport the hard or shaped materials, like iron ore, diamond, copper and other minerals.

3) Oil Resistant Belt

Generally used for wood, papermaking, oil-based grain transportation.

4) Acid/Alkali Resistant Belt

Always used in Chemical materials transportation.

5) Cold Resistant Belt

The belt can work in some cold environment, like Northeast of China, Russia and North European countries.

6) Fire Resistant Belt

Always used in underground coal mining, steel works and so on.

7) conventional Belt

Generally used for small powder, grain and block materials.

FAQ

Why you choose us?

1.Super high quality.

2.Competitive price.

3.Good producing equipment and technology.

4.Large production ability.

5.Prompt delivery.

6.Small order accepted.

7.Excelent sale and after-sale service.

8.OEM available.

Is the product sample available?

Yes,all product samples are available for you to test the quality.

Is OEM available?

Yes,OEM is available.We have professional designer to help your brand promotion.

Are the products tested before shipping?

Yes,all of our products were qualified before leave the factory,we test every batch every day.

Delivery details?

Within 10-20 days in general or depends on quality of the order.

Packaging details?

Packed in rolls and covered by nylon water proof cloth.Clients' requirement are also respected.

What's the quality guarantee?

We have totally quality guarantee to customers,we will be responsible for any quality problems.

Product name: Fabric Conveyor Belt
