HB-TN203 400w low frequency induction flood light

Specifications

HB-TN203 400w low frequency induction flood light

1. Wide voltage range design(100-300V): 40-400W all series wide voltage range design (100-300V), which entirely meet the requirements using in 100V, 120V, 220V, 240V, 277V grid.

2. Designed according to electromagnetic compatible circuit standard: EMC meet GB17625, EN55015 standard.

3. Outdoor special protect function: Add the thunder and anti-surge current function; Insulation Paint process is used on electronic ballasts, which can dampproof, dustproof, anti-oxidation to ensure the lifetime of the outdoor products.

4. Protect function under the abnormal condition (open circuit, electric leakage, short circuit): No high voltage, heavy current, high-power appear during the protect process, improve the product stability, which ensure that the ballast won’t be damaged if the tube load is under any abnormal conditions.

5. Smart sweep frequency start:: Ensure every lights can be lighted up while they are used on a large scale. Avoid the circumstance that the light cannot work normally because of bad environment or voltage instability.

6. High quality import electronic device and IC design: Good stability, good warranty of product lifetime. For example, The United States stmicroelectronics Co.,Ltd FET. The U.S. IR chip companies, electrolytic capacitor Nichicon Corporation of Japan, Taiwan thick sound resistance, capacitance Singapore, etc.

7. High power factor: The power factor of AC external induction lamps 23-400W is 0.98, input current is the smallest under equal power.

HB-TN203

Work Frequency: 230KHz

LIGHT FIXTURE

Type: HB-TN203

Category: Tunnel Light

Size: 1005*315*230mm

Package Size: 1015*330*260mm

Net Weight: 16.4kg(100-300V), 16.9kg(185-300V)

Gross Weight: 17.4kg(100-300V), 17.9kg(185-300V)

Lamp source: HB Induction Lamp(square)

Power: 400W

IP grade: IP65

HB-TN203   include Tube, Ballast,Fixture .

Applications:
Tunnel, Underground Urban Lighting Projects.

 Light Distribution Curve                                                   Engineering Figure

Structural features:

1. High-pressure die-cast aluminum lamp housing and electrical box, the electrical and lamp separation, improved heat dissipation and independent power sealing products.

2. Professional induction lamp reflector surface structure design,more suitable for non-polar light source emitting at light pattern matching, reflective surface with mirror reflective treatment process

3. The unique buckle lighting design, using both sides open the way to ensure that the lighting installation is convenient to open.

4. The new silicone rubber seals to improve the product seal level.

5. High-strength glass, high transmittance, impact resistance.

6. Match up our company HB rectangular, round lamp, with high luminous efficiency, long life, good color,stable and soft light, no flicker, wide energy-saving, color temperature range of features.
