High Quality Sand Mining Pump & Slurry Pump

Product Name : High Quality Sand Mining Pump & Slurry Pump

Brife Introduction : Centrifugal Slurry Pump

A H series slurry pump are cantilever,single suction,separable double casing structure which ensure the pump operation safely.The wet parts including mental and natural rubber materials, they are interchangeable.

Slurry pump working part disassembly drawing:

Features :

1).  Cantilever, horizontal centrifugal slurry pump

2).  Excellent hydraulic performance, high efficiency, and low wear rate

3).  Better wear-resistance and corrosive resistance

4).  Frame plate for type  pumps have replaceable wear-resistant metal liners or rubber liners. The

       impellers are made of wear-resistant metal or rubber

5).  In allowable pressure range, it can be used in series in stages, and allowable

      maximum working pressure is 3.6Mpa.

6).  Centrifugal seal, mechanical seal and packing seal are available .

7). The discharge branch can be positioned at interval of 45 degrees by request and oriented to any

       eight positions to suit installations and applications.

Models and introductions

Materials Test Machine: Orient Spectrometer

Applications

This Series of Pumps are used conveying abrasive or corrosive slurry, especially clinker of power plants in electric power, metallurgy, mining, coal, building materials, chemical industry and other industrial sectors,etc.

Meeting international standards

The quality management systems of Nainater slurry pump are accredited to ISO 9001:2000 and our environmental management systems are accredited to ISO 14001:2004.
