metal non-metal multifunctional cutting bed BCL-XM/BM series

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Qingdao Tianjin Shanghai Guangzhou Ningbo Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Laser Type	CO2
Applicable Material	Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Wood, Other, Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Wood, steel	CNC or Not	Yes
Cooling Mode	Water Cooling	Graphic Format Supported	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin	Shandong, China	Brand Name	Bodor
Certification	CE, SGS, Other, CE, SGS, FDA	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

cutting bed BCL-XM/BM series
Economical and high cost performance
could meets your cutting requests for different materials

Product Description

Main Features

1.Economical with cost-effective metal and nonmetal laser cutting machine.
2.Stable machine's quality(2-year warranty),with comprehensive cutting applications(both able to cut stainless steel,carbon steel,arcylic,etc. metal and nonmetsl)
3.Lower investment cost,lower operating cost and lower maintance cost.
4.Non-contact height-adjusting configuration enables to cut almost all materials with lowest cost.
5. Working table: Open blade with special treated material. Never fray and easy operation, suitable for all kinds of hard materials.
6. Steady chassis: Stability and precision during high speed work.
7. Moving system adopts Taiwan HIWIN linear guide and precision gear, matched up with advanced DSP-controlled 3-phase stepper motor to ensure the working accuracy.
8. High efficiency tube with stable laser path, life time around 10000 hours.

Technical Parameter

Model	BCL1309XM	BCL1325BM	BCL1630BM	Option
Working Area	1250*850mm	1200*2500mm	1500*3000mm	According to Demands
Laser Power	150w mixed cutting laser head mixed-cutting laser tube
Laser Type	CO2 Sealed Laser Tube, 10.6μm
Cooling Type	Water Cooling
Laser Output Control	(0-100% Set by Software )
Smallest Character Engraving	Chinese: 2.0mm2.0mm, English Letter: 1.0mm1.0mm
Highest Scanning Precision	4000DPI
Positioning Accuracy	±0.05mm/m
Positioning Speed	20m/min
Max. Cutting Thickness	40mm
Max. Cutting Speed	20m/min
Controlling Software	DSP Control System
Graphic Format Supported	DST PLT BMP DXF DWG AI LAS, etc
Compatible Software	TAJIMA, CORELDRAW, PHOTOSHOP, AUTOCAD, All type of AUTOCAD software in cloth
Color Separation	Yes
Drive System	High-precision 3-phase Stepper Motor
Auxiliary Equipments	Exhaust Fan and Air Exhaust Pipe
Power Supply	AC110V/220V+10%,50HZ/60HZ

Applications

Applicable Industries:
Garments sampling, large format tailoring ,leather industry ,shoemaking ,decoration,furniture ,advertisement, packing and printing ,molding and artcrfts industries,etc.
Applicable Materials:
non-metal materials: cloth, leather, paper, wood, bamboo, plexiglass, glass, thin film ,canvas etc.
Metal materials: stainless steel , carbon steel
