Gabion Box,Gabion Baskets

Gabion box is galvanized double twisted hexagonal woven mesh with a rectangular box shape. It shall be assembled individually and placed on the surface to the lines, with the position of all creases and that the tops of all sides are level. Gabion box is being used to construct an access track along the length of an existing train station. The access track will be used by a pilling rig that will be required to place new foundation when the existing station is demolished and the new railway station constructed. All gabion boxes shall be properly staggered horizontally and vertically according to the construction requirement. Finished gabions products shall have no gaps along the perimeter of the contact surfaces between adjoining units.

Gabion Box specification:

1.Material of Gabion: high galvanized low carbon steel wire, Galfan wire and pvc coated wire

2.Gabion Box is made of high galvanized low carbon steel wire or intertwisted wire by double intertwist with machine or forming hexagonal structure. The quality conforms to BS443, BS1052.

3.resin film (PVC,PE) conforms to ASTM D412,ASTM D719

4.Gabion Box material is supported by ISO9001:2000

5.Base on international standard of EN 10223-3

Mesh Size:60x80mm

Inner Wire Dia:2.4mm

Selvedge Wire:2.7mm

Tying Wire:2.0mm or 2.2mm

Regular Gabion Box Size:1.5x1x1m, 2x1x1m, 3x1x1m, 2x1x0.5m, 4x1x1m, 3x2x1m, 4x2x1m

Mesh Size:80x100mm

Inner Wire Dia:2.7mm

Selvedge Wire:3.4mm

Tying Wire:2.0mm or 2.2mm

Regular Gabion Box Size:1.5x1x1m, 2x1x1m, 3x1x1m, 2x1x0.5m, 4x1x1m, 3x2x1m, 4x2x1m
