Double-head CNC Precision Cutting Saw LJZ2FB-CNC-550x6000

l         Equipment Features

1.The cutting angle adjust Automatically

2. Adopts the gas-liquid damping cylinder, assure the cutting stability

3. High-precision imported electric saw, cut face smooth

4. Direct input the processing size, no need back to the reference point if cutting the different length of profile

5. Imported servo motor on the cutting head driven by a belt drive, moving fast, the whole closed-loop control, cutting with high precision

6. The saw has a dynamic opening and closing cover, safe and reliable, good working environment

7. Cutting head movement and feed are used linear bearing motion pair;

8. The profiles can be entrusted with the moving material frame, compact structure, small machine space

l         Technical Parameter:

Power supply:        380V   50Hz

Motor:    2×2.2Kw     Rev 2800r/min

Operation air pressure:        0.6~0.8MPa

Air consumption:        60L/min

Blade specification:        φ500×4.4×φ30  Z=120(Standard)

                     φ550×4.4×φ30  Z=120(optional)

Cutter feeding speed:        stepless speed regulation 0~3m/min

Moving speed:            0~8m/min

Cutting length:       max  6000mm

          min  450mm

Cutting width:       130mm(φ500)   155mm(φ550)

Cutting height:       210mm(90°)

Cutting angle:       45°,90°

Repeat locating length tolerance:±0.2mm

Cutting profile surface plane:  ≤0.1mm

Cutting angle tolerance:    ±5′

Cutting profile surface roughness:  Ra12.5μm

Dimension:        7350mm×1450mm×1650mm

Weight:         2500kg
