6 in 1 functional heat press sublimation printing machine

Technical Parameter

   Specification:
Color:  Black
Voltage:  220/110V
Power:   1000W
Temperature Range:   0-399°C
Timing Range:   0-999Sec.
Diameter 7.5~9cm or 5~7.5 for Mug
Diameter 11cm or 15cm for Plate
Diameter 15x8cm for Baseball Cap
Diameter 29x38cm for Flat
Gross Weight:   25.5KG
Size (L W H):   51*49*47CM

product pictures

temperature and time request for heat transfer are as follows

(as reference):

 Pure cotton dress:    200 °c,            25 seconds

Polyester dress:        180 degrees, 15 seconds

Metal plates:               180 degrees,  40 seconds

Pearlescent Board:   180 degrees, 120--180 seconds

Metal pendants:         180 degrees,  60 seconds

Mouse pad:                 180 degrees, 15 seconds

China plate:                 200 degrees,  40seconds

Porcelain plate:           200 degrees, 180 seconds

Mugs:                            200 degrees, 180 seconds

Key chain:                    180 degrees, 100 seconds

Priduct specification

1.The machine is a combination of 6 parts, which are 1 t-shirt printer +1 cap/hat printer +2 mug/cup printers+2 plate printers.

2.Brand new slideway design is adopted, so it is easy and fast to replace parts.

2. Automatic count down button and self-clocking alarm.

3. Digital double control :The controller uses microprocessor program, parameter memory, so the control accuracy is much higher .

4.For the controlling heating chip, it uses the new degree Celsius, so the power is more stable, and the circuit board will not break down when the voltage is not steady.

5. Heating thermocouple: adopting new generation “K” updated version heating thermocouple. With double lines merged, it is safer and not easily broken down. (The glass tube is adopted for traditional ordinary machinery to pack thermistor. Once in case of unstable voltage, it will be easily broken down, burn out or crashed into pieces due to the uneven pressure!)

6. The aluminum plates are all upgraded and thickened, the quality becomes more secure and the phenomena of uneven base board and carrying capacity are avoided. The upgrading of quality, material and technology further guarantees the quality!

7. Can be lifted, lowered and rotated by 360 degrees and convenient to retrieve articles and transfer of alien articles;

8. Adding one heat-resisting foaming silicon on the baseboard, which can stand 400 centigrade degrees and will not deform.

Why choose us

The six sping press design can make sure the press evener.

  Dual display control box

How to operate the machine

choose plug you need
