Cutting and Slitting Machine
- Shanghai China
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | zhongyuan | |
| Model Number | ZYYX | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Cutting and slitting machine
Certificate: ISO, CE,
Lifetime services
Control system: Mitsubishi PLC with touch screen.
Product cut-to-length.
Engineer overseas installing and training available
15 years skillful engneers to design and make your machine.
Product Feature:
This cutting and slitting machine is the special tool for cutting and slitting steel sheet.
1.Technical parameter:
Item | Specification | |
Material | Type | Pre-painted steel coil |
Thickness(mm) | 0.3-0.7 | |
Width of steel sheet | Maximum 1250mm | |
Yield strength(mpa) | 235-345 | |
Slitting width | 80mm-1250mm | |
Slitter material | Cr12 mould steel | |
Cutter material | Cr12 mould steel | |
Numbers of Slitting blade | 6 pairs | |
Working speed(m/min) | 15times/min | |
Type of cutting | length-set cutting | |
Size of machine | 2500mmX1700mmX1400mm | |
Control mode | Mitsubishi PLC | |
Operating mode | Button + Mitsubishi Touch screen | |
Electric condition | 380V/3Phase/ 50HZ (or customize) | |
Main motor power | 4 KW | |
Hydraulic station power | 2.2 KW | |
2. Components of machine:
Decoiler | 1set |
Guiding device | 1set |
Leveling system | 1set |
Hydraulic cutting system | 1set |
Controlling system | 1set |
Slitter device | 1set |
Cutter device | 1set |
Outputs table | 2 pieces |
3.Process flow:
Decoiling material→covering film →Guiding system →Slit sheet into pieces →Cut to length
About us
We are professional in making roll forming machines since 2003.
Company occupies 6650, in which 5650 for workshops.
1. Capacity: 12-15 sets/month
2. Delivery: in only 5-8 weeks for urgent order
3. Have our own tool center. 12 sets CNC machines to process machine rollers.
4. Zhongyuan is a "All-in-house source"
--from raw material to the final high-precision forming machine. We have our precise tooling center.
5. Over 15 years engineers to design and make your machines.

1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome you visit us and test machine by yourself in our factory.
6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.
7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are ALIBAB’s Gold supplier with BV assessment (Audit report can be provided).
We join Alibaba Trade Assurance.
8) What should I provide if I`d love to customized my machine?
A: To customize machine, we`d love to know:
1. Profile drawing
2. Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
3. Voltage: designed per your requirement
4. Configuration requirement: Hydraulic or manual decoiler/ stacker
Have no idea about them?
We will be glad to recommend machines ----Just let us know your country!
9) How is your cooperate process?
A: Below is the cooperation flow chart
Lifetime services;
Technician can be sent to your factory to install the machine and train your workers
Get Free:
"Send" below to get profile drawing & design technical support by our 15 year experience technicians FOR FREE!

View Bureau Veritas Report :
Supplier Assessment Report(1) »»»»
Supplier Assessment Report(2) »»»»
Main Product Lines Verification Report »»»»
View company video »»»»
About Bureau Veritas »»»»
View detail of ISO9001 Certificate »»»»
