FC-IWAP portable charger for phone

Specifications

1. iWap IUC-2 is an exchangeable / expandable battery pack the most economic Eco Power Bank , which can recycle and reuse spare lithium-ion batteries installed to work as constant USB DC 5V power source to charge USB devices, by mean of its power transfer mobile charging function. IUC-2 also provides ordinary USB charger and universal charging tray for 3.6V / 3.7 V lithium-ion batteries. IUC-2 meets all charging needs and eliminates the trouble of carrying multiple chargers in your daily life.

2.iWapcan manually revive / recycle dormant malfunctioned lithium-ion batteries which are either over discharged or dormant malfunctioned after a long stored time, so as to pay back user’s investment on charger itself and prolong the battery life, which results in an environment protection and economic effect.

3.iWap is not only capable of charging up to 98% ( 3.6 V / 3.7 V) lithium-ion batteries sold on the marketplace but also all kinds of 3C devices which are charged with tip connectors via USB charger can be charged on iWap.

4. iWap’s patented invention battery polarity auto detection technology provides the user polarity free operation.

5. iWap’s unique power transfer design enable installed tray lithium-ion batteries to become an USB DC 5V, 500mA power source, which is powerful enough to charge one unit iPhone ( Smart phone) or 500 mA tip connector device.

6. iWap multi-tasks design can simultaneously charge up to 2 different 3C devices, thus, eliminating waiting time and the hassle of outlet sockets shortage; this means, one set of iWap charging capacities equal to the operation of 2 normal battery chargers.

7. iWap’s 3D sturdy battery holder can effect the function to withstand various vibration, so that such device is able to execute the proper charging process under the moving circumstances. iWap’s usages no locations limitations.

8. iWap’s 3R + 1 eco technology for lithium-ion batteries reduce, reuse, recycle + revival. It is truly economic effect, earth care as well as user friendly multipurpose battery charger.

1. iWap main unit x 1 set

2. USB power in cable x 1 piece

3. Part names and locations

To avoid redundancy, above illustration indicating part numbers will be introduced within the following pages.

4.Generic Specifications

Input Voltage : USB DC 5 V

Charging output voltage : 4.25 V, 500 mA (Max)

USB port DC 5V, Step up 500mA (Max)

Applicable batteries: 3.6 V / 3.7V lithium-ion batteries.

Cell phone charging: 1.5 ~3 hrs(depend on battery capacity)

Material : Plastics(ABS, POM)

Dimension: 9.5 x 7.5 x 4.0 (Lx W x H) Cm

Weight : 70 g
