55KVA Diesel Generator Set

55 kva Diesel Generator specifications:

Model: SFC55J

Prime Power: 40kw/50kva

Standby Power:45kw/56.5kva

Engine Brand: Cummins

Engine Model: 4BTA3.9-G2

Alternator Brand: Marathon

Rated Voltage: 380V/220V

Rated Currency: 76AM

Controller Brand: Deep Sea / Smartgen (Digital and intelligent)

LED Screen and touch Buttons’

Main Functions

1-      Display loading power, voltages, currencies, frequency, speed, temperatures, oil pressure, running time etc.

2-      Warning when low or high voltage, low or high frequency, over current, over or low speed, low or over battery voltage etc.

3-      Shut down when low or high voltage, low or high frequency, over current, over or low speed, low or over battery voltage etc

Optional Accessories of Diesel generator

1. ATS: Automatic Transfer switch, which can start the diesel generator when the main power is off; when the main power comes back, it will shut down generator.

   And ATS have the function of AMF (automatic Main power failure)

2.Soundprooof:The noise can be controlled under 60dB-70Db which do not influence our normal life.

2. MCCB (molded case circuit breaker), which can protect the loading machine and the diesel generator.

3. Battery charger (float charger): when you haven’t used the generator for a long time, the batteries will be no power, in that way, you can’t start the generator. If you have battery charger, you can charge the batteries by the charger from main power.

4. Base fuel tank; daily fuel tank;

5. Paralleling system; This system can make several generators work together and automatically distribute the load according to set.

6. Remote Control Panel; we can control the generator by computer, if we use a RS484 or RS232 digital cable to connect the generator to our computer.

7. Water separate; If the ambient temperature is too high, it will be harmful to our the diesel generator. Fan and water cooling is not enough for radiate. If we use water separate system, the life of generator will be much longer.

8. Spare Parts of Cummins engine: we can supply spare parts for our Cummins diesel

generators too at very competitive price.
