Dongfeng 6x4 Concrete Silos Mixer Vehicle

SPECIFICATION

Chassis model

DFL5250GJBA

Drive

Left Hand Drive or Right Hand Drive

Drive model

6×4

Wheelbase

1^st axle-2^nd axle

2^nd axle-3^rd axle

3650mm

1350mm

Complete Dimensions

(L×W×H)

8960*2500*3910mm Only for reference, should be subject to the existence.

Engine

L340-33

250KW 6 Cylinder, Turbo Diesel,340HPs/2100RPM, Displacement 8900ml, Euro 2 emission standard, water cooling diesel engine.

Gear box

SHANXI FAST-9 Gear-box Made in China ,9 forward+ 1 reverse

Suspension

Leaf spring  8/12

Clutch

Φ430mm, pushing-type Diaphragm spring.

Brakes

Service brake: Two-circuit air pressure braking.

Parking brake: Air pressure braking

Exhaust brake: Air pressure braking

Steering

Power steering, with adjustable steering wheel.

Frame section(mm)

300×90×(8+6)

Tyres

11.00-20

Electrical system

Alternator 28V/80A,Batteries 12V/175Ah

Fuel tank capacity

200L, Steel tank.

Kerb weight

14305kgs

Axles loading capacity

Front

Rear

7,000kgs

13,000kgs ×2 (single stage reducer)

Cab

D310 Single sleeper, tilt cab hydraulic and mechanical overturn cab, left-hand drive.

Accessories

Tool box, Air conditioner, cold boot, inter axle differential

performance

Max. speed 85km/h

Tank Geometric volume

14.3m3

Valid mixing tank volume

9m³

Type of tank board

The mixing drum is made of 5mm thick Mn steel, and the ends of drum are 6mm thick.

Tank wielding

automatic welding

others

Rexroth(Germany)hydraulic motor and pump, ZF (Germany) redactor 350L pneumatic storage tank

Feed rate

≥3 m³ /min

Discharge rate

2 m³/min

Residual rate of discharge

<0.7%

Work condition

City transport concrete or sand puld or in bad road
