HOWO 8x4 Road Wrecker Truck
- Any port of China
- T/T
You May Like
Product Details
| Fuel Type | Diesel | Emission Standard | Euro 3 | |
| Condition | New | Transmission Type | Manual | |
| Dimensions (L x W x H) (mm) | 11420*2496*3456 | Place of Origin | Hubei, China | |
| Brand Name | HOWO | Model Number | ZZ1317N4667C |
Product Description
Specifications
1.Multi-function wrecker truck2.Strong lifting crane
3.360 degree boom
4.Long lifting boom
5.HOWO 8x4 chassis
1.Multi-function wrecker truck
2.Strong lifting crane
3.360 degree boom
4.Long lifting boom
5.HOWO 8x4 chassis
Parameters of this wrecker truck | ||
Chassis model | ZZ1317N4667C(with air condition) | |
Crane type | 360-degree rotating crane, hydraulic supporting arm, manual clamp, and four support ground jacks. | |
Curb mass (kg) | Curb weight | 24500 |
1,2 axles | 6990/7000 | |
3,4 axles | 10510 | |
Total mass (kg) | Total weight | 31000 |
1,2 axles | 5810/5820 | |
3,4 axles | 24000 | |
Vehicle size(mm) | Length | 11420 |
Width | 2496 | |
Height | 3456 | |
Truck’s Wheelbase (mm) | 1800+4600+1350 | |
Track (1-4 axle) (mm) | 2022/2022/1830/1830 | |
Front hang (mm) | 1500 | |
Rear hang (mm) | 1620 | |
Approach angle (°) | 13.7 | |
Departure angle (°) | 14.1 | |
Drive type | 8×4 | |
Tyre size | 12.00-20 | |
Mas speed (km/h) | 90 | |
Minimum turning diameter (m) | 24 | |
Minimum ground clearance (mm) | 298 | |
Engine | Model | WD615.95E |
Power (kW/r/min) | 247KW/2200 | |
Fuel consumption per hundred kilometers(L/100km) | 34 | |
Lifting boom | Basic boom length(mm) | 6030 |
Boom total length (mm) | 9530 | |
Working stroke cylinder (mm) | 3500 | |
Pitch to the maximum lifting height (mm) | 9850 | |
Max lifting mass of the crane (kg) | 22000 | |
Winch | Double 10 T winch | Line length 40 meters |
Corbel | Max effective length (mm) | 2950 |
Stretch travel (mm) | 750+750 | |
Lifting travel (mm) | 650 | |
Rated lifting mass (kg) | 20000 | |
Rated draggling mass (kg) | 60000 | |
If need more information,please feel free to contact me.
Welcome to visit our company in China!
