New Dongfeng 6x4 truck mounted 10tons crane SANY
- 1000 Unit / Units per Month
- Any port of China
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Full rotation | |
| Rated Loading Capacity | 10000kg | Rated Lifting Moment | 25t.m | |
| Max. Lifting Load | 10000kg | Max. Lifting Height | 16.5m | |
| Span | 14.5m | Place of Origin | Hubei, China | |
| Brand Name | SANY | Model Number | SPS25000 | |
| Certification | CCC,ISO9001 |
Product Description
Specifications
1.Dongeng 6x4 truck mounted crane2.Famous SANY crane 10tons
3.Crane model SPS25000
4.Stable performance
5.Good price
1.Dongeng 6x4 truck mounted crane
2.Famous SANY crane 10tons
3.Crane model SPS25000
4.Stable performance
5.Good price
Chassis | Chassis Model | DFL1250A12 | ||
Drive Mode | 6X4 | |||
Tire | 10.00-20 | |||
Quantity of tires | 10+1 | |||
Brake | Air brake | |||
Steering system | Power steering | |||
Engine | Model | C260 33 | ||
Output power (kw/Hp) | 191/260 | |||
Displacement(ml) | 8300 | |||
Max.torque(N.m) | 1090 | |||
Emission level | Euro III | |||
Main Parameter | Dimension (MM) | Overall dimension (L*W*H) | 11960*2500*3670mm | |
wheelbase | 5350+1300mm | |||
Axles No. | 3 | |||
Cargo box | 8500×2290×600mm | |||
Weight (KG) | Gross weight | 25000kg | ||
Curb weight | 15500kg | |||
Leaf spring No. | 8/9,8/10,9/10 | |||
Approaching/Departure Angle(°) | 20/8 | |||
Front/Rear Track(mm) | 1986/1860,1860 | |||
Max speed(km/h) | 80 | |||
Gear Box | FAST 9JS119A 9 forward gears, 1reverse gear | |||
Front/Rear Axle Load (kg) | 7000/18000(Tandem) | |||
Crane | Brand | SANY | ||
Model | SPS25000 | |||
Max. hoisting weight | 10000kg | |||
Max.hoisting moment | 25t.m | |||
Max. flow of hydraulic system | 63/32L/min | |||
Rated compressure of hydraulic system | 28Mpa | |||
Volume of hydraulic oil tank | 180L | |||
Dead load of crane | 4200kg | |||
Installation space | 1350mm | |||
Rotation angle | 360° full rotation | |||
Quantity of crane arms | 4 sections | |||
ing range | 14.5m | |||
Max. Hoist height | 16.5m | |||
Main arm length | 5400mm | |||
Full arms length | 14800mm | |||
Front ground jack span | 2280/5600mm | |||
Rear ground jack span (Optional) | 2219/4759mm | |||
Max. Angle of elevation | 75° | |||
If need more information,please feel free to contact me.
Welcome to visit our company in China!
