YL-1000 series Cardboard Box (V Mould) Groove Cutting Machine Line,Paper Box Groove Cutting Machine
- Ningbo Port China
- T/T Credit Card
You May Like
-
YL-1000 Type Series (U Model) Cutting Groove Machine with Rotary Drum for wholesales
-
2016-YL-1000 Paper (L Type) Groove Cutting Machine Production Line for Cardbaord Box
-
YL-1000 Series Ruian (V+U+L Model) Rotary Drum Type Groove Cutting Machine Line for Paper Box(Boxes)
-
YL-1000 Series Professional Engineers Groove Cutting Machine with Rotary Drum Type which can make Paper V+U+L Mould
-
YL-1000 Series Electric Rotory Drum (V+U+L) Type Groove Cutting Machine Product Line for Gaine Box
-
Cardboard V+U+L Type CNC Rotary Drum Type Cutting Groove Machine YL-1000 Series
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Usage | Paper Forming Machine | Place of Origin | Zhejiang, China | |
| Brand Name | Yinlomg Brand | Model Number | YL-1000 | |
| Voltage | 380V | Power(W) | 2.2kw | |
| Dimension(L*W*H) | 1640x1100x1600 | Weight | 1200kgs, 1200kgs | |
| Certification | ISO CE | Warranty | One Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Rotary Drum Type Cutting Groove Machine
Model No.YL-1000
Main characteristics
1. Environmental protection,clean,no noise(under the angle materials to note);
2. The machine used for gray cardboard,MDF and other cardboard cardboard V V slot,slot to
high precision tool life efficiency characteristics.
3. Model small,small occupation area,low power consumption(2.2kw) saves the cost
expenditure,open out of the V slot no burrs,no dust,To open up a root of recyclable waste.
4. The machine can also be adjusted to a variety of angles,out more exquisite products.
5. This machine is specially equipped with a grinding machine,grinding a knife needs 2-
3minutes,10 hour can produce about 10000 boxes.
MAIN TECHNICAL PARAMETERS | |
Model | YL-VK-1000 |
Processing board | 100-900mm |
Slot pitch | 0-800mm |
Board thickness | 0.5-32mm |
Maximum slot number | 8 |
Several slot | 1030m/min |
Weight | 1200kg |
Total Power | 2.2kw/380v |
Dimensions(L x W x H) | 1640x1100x1600mm |
