High quality PEEK plate

High quality PEEK plate

Data sheet is available, ask us if you need it.

PEEK product group:
1. PEEK+Glass fiber
2. PEEK+Carbon fiber
3. Medical grade PEEK, 30 days and permanently implanted are both available.Ceritificate is available.
4. Food grade PEEK

PEEK are available:
rod, sheet, tube,  part

Quick Detail:

Temperature 250°C resistance Carbon fiber filled PEEK rod
Wide thickness range available: 6mm ~ 50mm
SGS RoHS approved


Description:

Trade names:
Polyether etherketone, Carbon fiber filled PEEK rod
Available Shapes:
Sheets, Rods, Tubes,Plates
Color:
Natural
Rods Diameter:
6.0mm ~ 150mm
Length:
500mm ~ 1000mm or customized

About PEEK Rod & Sheet:

PEEK is a high performance engineering thermoplastic that offers chemical and water resistance similar to PPS, but can operate at higher temperatures. PEEK can be used continuously to 480°F (250°C) and in hot water or steam without permanent loss in physical properties. For hostile environments, PEEK is a high strength alternative to fluoropolymers. PEEK carries a V-0 flammability rating and exhibits very low smoke and toxic gas emission when exposed to flame.


Advantages:

Excellent chemical resistance
Very low moisture absorption
Inherently good wear and abrasion resistance
Unaffected by continuous exposure to hot water or steam
High temperature resistant, can withstand 250°C


Key Features:

Strong and stiff plastic
Outstanding chemical resistance
Good mechanical properties at elevated temperatures
Resistant to hot water and steam
Bearing grade PEEK has excellent wear characteristics
UL 94 V-0 flammability rating (0.059" thickness)
Very low smoke and toxic gas emissions when exposed to flame


Applications:

Semiconductor machinery components
Aerospace parts
Seals
Pump and valve components
Bearings and bushings (bearing grade PEEK)
Electrical components
Medical instrument parts
Food processing machinery components


Note: Usually, the color and length can be customized, width will according to the available extrusion mould or molding mould. Tolerance for length, width, diameter and thickness may vary when manufacturing. More information, please feel free to contact us online or by email.

PEEK Technical Data Sheet
Technical Data	Method of Verification	Unit	PEEK
I.Physical Properties
Density	ISO 1183	g/cm3	1.31
Water absorption	ISO 62	%	0.06
II.Mechanical Properties
Tensile strength at yield	ISO 527-2	MPa	97
Tensile strength (psi)	527	MPa	110/-
Tensile Modulus (psi)	527	MPA	4400
Flexural strength (psi)	527	MPa	110/-
Compressive strength (psi)	604	MPA	29/57
Coefficient oflinear expansion(23-100°C)		m/(m.k)	50×10-6
Thermal conductivity	C177	Btu-in/hr-ft2-°F	1.7
Tensile strength at break	ISO 527-2	Mpa	-
Elongation at break	ISO 527-2	%	25
Modulus of elasticity after tensile test	ISO 527-2	MPa	-
Modulus of elasticity after flexural test	ISO 178	MPa	4,200
Hardness-Rockwell	ISO 2039-2		-
Hardness - Shore D	DIN 53505		88
Charpy impact strength at 23 C	ISO 179	kJ/m2	N.B.
Friction coefficient	DIN 53375		0.34
III.Thermal Properties
Heat deflection temperature - HDT/A	ISO 75-2	C	152
Max. service temperature - Short term		C	300
Max. service temperature - Long term		C	260
Thermal conductivity at 23 C	DIN 11359	W/(K*m)	0.25
Coefficient of linear thermal expansion	ISO 11359	10 -4* K -1	0.47
IV.Electrical Properties
Dielectric constant at 1 MHz	IEC 60250	10 6 Hz	3.20
Dielectric loss factor at 1 MHz	IEC 60250	10 6 Hz	0.003
Volume resistively	IEC 60093	Ohm (Ω) * cm	≥10 16
Surface resisively	IEC 60093	Ohm (Ω)	≥10 15
Dielectric strength	IEC 60243-1	kV/mm	19
V.Miscellaneous Data
Flammability	UL 94	Class	V-0
NOTE: 1 g/cm3 = 1,000 kg/m3, 1 Mpa = 1 N/mm2, 1kV/mm = 1 MV/m
Statement:
NOTE: The information contained herein are typical values intended for reference and comparison purposes only. They should NOT be used as a basis for design specifications or quality control. ENERGETIC will not provide any legally binding guarantee of certain properties, or any suitability.

 Packed in wooden pallet or wooden boxes or customized. See pics as below

Plastic Fabrication & Machining

Based on the drawings and samples, we can machine any plastic at a competitive cost. Why choose us to do the jobs for you?

u Almost all materials are in stock, we produce the materials in our own plants but not buy from others, therefore you save the cost in materials.

u Various and completed equipments to ensure the quick production and precise dimensions.

u Engineers are of more than 10 years experiences, they know the performance of all plastics and how to machine the plastics parts in the best way.

Plastic Injection

After many years in plastic industry, we found that many customers who have requirements on plastic injection service. We start to do plastic injection from 2013, we only provide plastic injection service for some big components, you can check some examples as below. Materials are usually in ABS, POM, HDPE, PP and PVC.

Plastic & Rubber Profile Extrusions

We are able to produce some plastic extrusions profiles at unbeatable prices. In general, materials are HDPE, Nylon, POM, PTFE , UHMW PE, TPE, TPO, EPDM,etc.

Plastic welding rods are available, can be ABS, PVC, PP, PE, PA6(nylon) POM, PTFE,PC, TPO, TPE, TPV, EPDM. Check some examples as below:

Dezhou Kuhi Import & Export Co., Ltd

Dezhou Kuhi Import & Import Co., Ltd(Kuhi) established in 2010 as a dedicated manufacturer of Engineering Plastics, and its branch company Energetic is recognized as a leading supplier in Chinese market, with focus on Engineering and Industrial materials. Kuhi and Energetic has developed a reputation for service and quality. They are always able to provide you high cost-performance & right material.

Plant 1: Xitang Industry Zone, Ningjing County, Dezhou, Shangdong Province, China

Plant 2: No.113, RD Hexie, Xinhe County, Xingtai, Hebei Province, China

Tel: +86-534-7059066 Fax.:+86-534-7059068

Branch Company(Shenzhen):

Energetic Industry Co., Ltd(HK)

Add.: No. 103, Shuxiang Rd., Xinmu, Pinghu Town, Longgang District, Shenzhen, China 518111

Tel.:+86-755-28326940  Fax.: +86-755-28326940

Sales Manager: Mozart Jiang

Cel/whatsapp:+86-18923742060

Skype:01

Email:mozart@cn

Q: Do you provide free samples?

A: Yes, but freight will collected. If you have a courier account, that's good. If not, you can pay the courier fee via Paypal, Western union, Moneygram.

Q: Do you have agent in overseas?

Yes, we do.  If you are from these countries, then you can buy our product locally. We have stable customers and agent in these countries.

Australia, Argentina, Brazil, Indonesia, Thailand, USA, Canada, Morocco, Honduras, Venezuela, Mexico, South Africa, Oman, Saudi Arabia, UAE, Israel, Vietnam.

Q: Do you work 7x24 hours?

A: Yes, you always can contact us at any time. You can get to us from direct call, Skype, Whatsapp, Facebook, Viber. Anyway, we prefer email.

Q: Are you a manufacturer or trading company?

A: Manufacturer, you can visit our plant, if you want.

Q: Do you have the ability to machine plastic parts? If drawings provided.

A: Yes, we do. You can send us 2D, 3D file, even a sketch.

Q: Do you have a MOQ?

A:  No, we do not.  Sample order is okay for us.

Q: Do you provide CNC service?

A: Yes,  Plastic Fabrication & Machining, plastic injection, plastic extrusion. Even metal&rubber.

Q: Do you have a catalogue?

A: Yes.
