Insulative 3240 Epoxy Fiber Glass Sheet

High Temperature Resistant Epoxy Resin Sheet

Color: yellow

Shapes Include: Sheets

Size:

I. Define and purpose

This laminated product is formed through heat pressing after electric industry alkali glass cloth dips into the epoxy phenolic resin. It has high mechanic and dielectric performance, and applicable as insulation structural components for electromechanical/electrical equipment, as well as used under damp environmental conditions and transformer oil .

II. Technical requirement for surface

The surface of laminated board should be flat and smooth, no bubble, no wrinkle, no delamination or crackle, and properly free from other defects such as scrape, impress, dirty spot and uneven color, but a little color patches is allowed.The surface of laminated board should be flat and smooth, no bubble, no wrinkle, no delamination or crackle, and properly free from other defects such as scrape, impress, dirty spot and uneven color, but a little color patches is allowed.

III. Characteristics

♦ High mechanical properties, and oil resistance and certain dielectric property.

♦ Thermal rating is 120, and temperature resistance : 150 centidegrees

♦ Withstand a variety of chemical solvents and acid erosion

VI. Application

Chemical machine parts , general machine parts and gear ,and generators, Pads, base, baffle etc.. Generator ,transformer, fixture, inverter, motor and electric insulation component

Other Grade

FR4, G10, G11
