Product Details
| Place of Origin | Guangdong, China | Brand Name | Lenoxy | |
| Model Number | fr4 epoxy sheet |
Product Description
Insulation plastic Laminated Sheets & Fabricated Parts GPO-3
Color:light green
Shapes Include: Sheets , Rods
I. Define and purpose |
This laminated product is formed through heat pressing after electric industry alkali glass cloth dips into the epoxy resin. It has high mechanic and dielectric performance, applicable as insulation structural components for electromechanical/electrical equipment, as well as used under damp environmental conditions and in oil of transformer. And it can Withstand a variety of chemical solvents and acid erosion. |
II. Technical requirement for surface | ||
|
III. Main technical specifications
Test Item | Unit | Material: Epoxy resin, fiber glass |
FR4 Epoxy | ||
Vertical layer Direction Flexural Strength Normal≥ | MPa | 340 |
Vertical Layer Direction compressive strength ≥ | MPa | 350 |
Parallel layer Direction IZOD Impact Strength simply-supported beam method ≥ | KJ/m2 | 33 |
Parallel layer Direction shearing strength ≥ | MPa | 34 |
Tensile Strength ≥ | MPa | 240 |
Vertical Layer Direction Electrical strength 900C, (in oil 20 seconds), Gradual step-up method | mV/m | 13.7 |
Parallel layer Direction VB(breakdown voltage)> | KV | 50 |
Relative dielectric permittivity 50Hz ≤ |
| 5.5 |
Dielectric loss module 50Hz ≤ |
| 0.04 |
Insulation resistance after immersion in water ≥ | Ω | 1.3×1012 |
Density | g/cm3 | 2.0±0.15 |
Water absorption Plate thickness 1.6 mm ≤ | mg | 19 |
Flammability | FV | 0 |
Heat resistance ≥ | 0C | 170 |
Color | Green | |
Size | mm | 1020×1220 |
Executive Standard | GB/IPC4101 | |
IV. Product Application
Chemical machine parts , general machine parts and gear ,and generators, Pads, base, baffle etc..Generator ,transformer, fixture, inverter, motor and electric insulation component.
V. Product Size
FR4/G10/G11 Epoxy Sheet | |
Thickness(mm) | Width/Length(mm) |
0.5-1.5mm | 1020mm×1220mm |
2—2.5mm | 1020mm×1220mm |
3--50mm | 1020mm×1220mm |
60--80mm | 1020mm×1220mm |
FR4/G10 Epoxy rod | |
Diameter(mm) | Length(mm) |
5mm--80mm | 1000mm |
90mm—170mm | 1000mm |
Related products
♦ G10/G11 Epoxy Glass Fiber Sheet
Color: Green
G10/G11 is a composite material combined with glass fiber cloth and epoxy resin, which can bear great pressure without damage and deformation. G10/G11 can’t be permeated by vapor and liquid and it owns good insulation and acid& alkali resistance characteristics.G10 can be FR4 by adding flame retardant but it becomes G11 by improving thermal flexural properties.
♦ Antistatic Epoxy Fiber Glass Sheet
Color: Black
Advantages: high density, low absorption, good heat resistance and dimension stability, good dielectric properties and mechanical strength.
Application: Be used for various testing jigs, flat of precise instrument and installment of electrical products
Surface resistivity: after finishing moisture-proof C-96/35/90: 106 ~109Ω
after high temperature E-24/125: 106 ~109Ω
Volume resistivity: after finishing moisture-proof C-96/35/90:4×108 Ω-cm
after high temperature E-24/125: 2×106 Ω-cm
III. Application
Chemical machine parts , general machine parts and gear ,and generators, Pads, base, baffle etc..Generator ,transformer, fixture, inverter, motor and electric insulation component.
