High Quality and Factory Price for Stainless Steel Solar Light Waterproof Outdoor Lamps Pole

Part Name and Lifespan

Technical Specification

Solar Panel:

Lifespan:20-25 years

250W*1PC Poly crystalline. High Efficiency. A-class

Adding Aluminum Frame, Tempered Glass.

Gelled Battery

Lifespan:5-8 years

100Ah/12V*2PC for 24V, Gelled battery, Sealed Type.

Deep cycle. Maintenance Free

Intelligent Solar Controller

Lifespan:5-10 years

15A/24V, IP68. Automatic Light and Time Control

Over-charging/discharging Protection

Reverse-connection Protection

Switch on Automatically with Light Sensor;

Switch off after designed Hours later

Light source: High Power LED

Lifespan: More than 50000-100000Hrs

60W LED, White Color, 7200LM,5600K, IP65

High Power, High Brightness.

Lamp Housing:

Lifespan: More than 20 years

Die-caste Aluminum, IP65

High transmittance & Density toughened glass,

Pole:

Lifespan: More than 20 years

8M Height, Steel, Hot-Dip Galvanized.

With Arm, Bracket, Flange, Fittings, Cable, Etc

Plastic Coated, Rust Proof,

Resistant to Wind: ≥150KM/H,

Battery Box:

Engineering Plastic,Burying Type Battery

System Certification

ISO9001,CE & EN, RoHS,IEC,SONCAP,FCC

Warranty

2 Years for full system

1.)Lamp Body: High-Pressure

    Die-Casting Aluminum. Corrosion Resistant

2.)Application with Polyester Substance in its Surface.
3.)Implement of Reflect: Made of High Purity Aluminum.

4.)Cover: High Strength and High Transparent

    Toughened Glass
5.)Fastener Bolt and Screws: Stainless Steel
6.)Arm Diameter: 60mm

7.)IP65

8.)Lumin:120-130LM/W;

Silicon Type………………………………Mono/Poly

Size……………………………………1500*670*35mm

N Weight…………………………………12.0KG

Vmp…………………………………………17.2V

Imp…………………………………………..6.89A

Voc………………………………………….21.6V

Isc……………………………………….……7.45A
Efficiency: …………………………………≥16.0%
FF(%)……………………………………….70-72%

Operating temperature…………….-40°C to +80°C

Number of cell ……………………………..…6

Design Life ……………………………5-8 years

10 hour rate(12.0A,10.5V) ……….……100Ah

Fully Charge battery 77°F(25°C) …. ….4mΩ

Discharge……………….……..………-20~60°C

Charge………………………..………..-10~60°C

Storage…………………………………-20~60°C

Size:……………………………406*172*210mm

Net Weight……………………………...30.0 KGS

Intelligent Micro-computer Controller

Temperature Compensation.

Size………………………………..81*60*20mm

N. Weight………………………….0.16KG
Working Temperature:-20°C to  60°C

Over-charging/discharging Protection

Reverse-connection Protection

Switch on Automatically with Light Sensor;

Switch off after designed Hours later.

IP68 Level.

Pole Height…………………………………8M

Material……………………………………..Q235,

Top Diameter…………………………….75mm

Bottom Diameter………………………..160mm

Pole Thickness…………………………..3.5mm
Weight:…………………………………85KGS

With Arm, Battery Box, Box Bracket,

Solar Panel Bracket.

Nuts and Screws, Cable, etc
Hot-dip Galvanized, Plastic Coated,

Rust Proof,

Resistant to Wind: ≥160KM/H
