outdoor highlight energy saving LED chip IP67 led street light
- Ningbo China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| LED Light Source | COB Bridgelux | Input Voltage(V) | AC85-265V | |
| Lamp Power(W) | 100 | Lamp Luminous Flux(lm) | referrence | |
| Lamp Luminous Efficiency(lm/w) | 110 | Color Temperature(CCT) | Other, 3000-7000k | |
| Working Temperature(℃) | -40, 60 | Working Lifetime(Hour) | 50000 | |
| Lamp Body Material | Aluminum Alloy | IP Rating | IP67 | |
| Certification | CE | Warranty(Year) | 5 | |
| Place of Origin | Zhejiang, China | Brand Name | MCLED | |
| Model Number | ML015 |
Product Description
outdoor highlight energy saving LED chip IP67 led street light
Apply to Roads, Highway, Highway Lighting, Bridge, Car Park, Garden, Park, Petrol Station, Sport Lighting, Square, Square Lighting
Key Specification
1.Input Voltage:AC85-265V
2.Frequency Range(HZ): 50-60Hz
3.Watt:50W-120W
4. Luminous Efficiency: >110lm/w
5.Power Efficiency: >95%
6. CRI: Ra>80
7. LED type: Bridgelux
8. Color Temperature:2700-7000K
9.Power Source: LED
10. Working Temperature(C): -40C~60C
11. IP Rating: IP67
12.LED street light housing is made from Alluminium die casting
13.High quality driver:MOSO
14.Working Lifetime: >50000hrs
15.Certification: CE, RoSH, PSE
16.Guarantee is 3~5 years
Technical Parameter
| Model Item | Ml015-50W~200W |
LED Power Consumption | 50W~200W |
System Power Consumption | LED Power ×1.1 |
Input Voltage | AC 100~265V |
Working Power Frequency Range | 47~63Hz |
Power Factor | >0.95 |
Total Harmonic Distortion | <20% |
Working Environment | Temperature:-40℃~60℃; Humidity: 0~100% |
Average Temperature in 24 hrs | ≤35℃ |
Surface Highest Temperature | ≤60℃ |
Junction Temperature(TJ) | <70℃ |
Lamp Luminous Efficacy(Lm/W) | ≥110Lm/W |
LED Initial Flux (Lm) | LED Power×110LM |
Lamp Efficiency (%) | ≥90% |
Color Temperature | 2500K~7000K |
Color Rendering Index(CRI) | Ra>75 |
LED Life Span | >50000 h |
Protection Grade | IP67 |
Lens Light Transmittance | ≥90% |
Beam Angle | 60°~160° |
Net weight | 9.5Kg |
Gross weight | 11Kg |
Packing size | L105×W41×H25.5cm |
Applications:
