Low Price Latest 0.35mm Infrared Ceramic Emitter Heater
- Shanghai/Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Resucerial | |
| Model Number | RE926-C | Type | Ceramic Heater | |
| Application | Heater Parts | Certification | CE |
Product Description
Specifications
0.35mm infrared ceramic emitter heater1.fast response, Rapid heat-up
2.Certificate: CE.
Low price latest 0.35mm infrared ceramic emitter heater
Ceramic infrared heaters are 96% infrared energy efficient.
Uses for electric infrared heat can be found in many industries applications,
and can be grouped into four major categories:
1. Curing.
2. Drying.
3. Heating.
4. Cooking.
5. Saunas.
Top right have has a wide range of IR ceramic heaters in ceramic and Quartz.
Available With thermocouple & without thermocouple from 60 watts to 1000 watts.
Feature of 0.35mm infrared ceramic emitter heater:
1. Durable, splash-proof, non-corrosive finish.
2. Watt densities from 3 w/cm² (tolerance within +/- 2%).
3. Maximum temperature output is 1292 F (700 C.).
4. Available color in white/ black/yellow.
5. Standard voltages: 220/230v (other volts available on request).
6. Estimated life in excess of 10,000 hours.
7. Available With thermocouple & without thermocouple.
Parameter of 0.35mm infrared ceramic emitter heater:
| Model | RE926-C |
| Brand | Resucerial |
| Applications | Plastic thermoforming,Blowing of plastic bottles, chemical industry, light industry, electronics, medicine, food |
| Radiation Wavelengths | 1-25um |
| Certificate | CE |
| Life Time | 1500h |
| Heating Resistance Wire | Ni-Cr-Al Alloy wire |
| Material | quartz sand |
| Shape | flat,curved |
| Color | white/black/yellow |
| Voltage | 12v,24v,36v,75v,110v,120v,220v,230v,240v,380v,400v,415v |
| Watts | 100-2000w |
| Sizes(Mm) | 245x65,240x60,120x60,120x120 |
| Power Dflexural Strengthensity | 440kg/cm2 |
| Insulation Resistance | >100megohm |
| Emissivity | 0.9 |
| Largest Surface Load | 5w/cm2 |
Size(mm) | Shape | Power( KW ) | Size(mm) | Shape | Power(KW) |
245×65 | arc | 0.25-1.0 | 300×300×16 | flat | 0.8-1.5 |
240×60 | arc | 0.5-1.0 | 240×160×16 | flat | 0.6-1.0 |
125×65 | arc | 0.2-0.5 | Φ70 | disk | 0.1-0.2 |
120×60 | flat | 0.1-0.325 | Φ100 | disk | 0.2-0.3 |
120×60 | arc | 0.1-0.325 | Φ140 | disk | 0.3-0.4 |
120×120 | flat | 0.1-0.8 | Φ150×Φ100×Φ60 | half | 0.25-0.3 |
120×120 | arc | 0.1-0.8 | 125×125 | flat | 0.4-0.8 |
Photos of 0.35mm infrared ceramic emitter heater:
Samples:
Application of 0.35mm infrared ceramic emitter heater:
1. The ceramic heaters are widely used in pre-heating of plastic sheets for vacuum forming & thermoforming, drying paints, lacquer & varnish curing, drying printing inks, drying textiles, activating adhesives, removing surface water from objects or moisture removal from fabric and paper, animal husbandry and rearing.
2. The ceramic IR heaters are highly efficient.
3. Ceramic infrared heater offers precise targeting and control with minimal peripheral heat.
4. It is possible to apply heat only where and when it is required.
5. The energy in an infrared heater is transmitted at the speed of light from the element to the product.
6. A constant rate of heating is obtained because the source temperature is normally much higher than that of the product even at the end of the heating cycle.
Certification:
Production Process:
Packing:
Shipping:
Our Team:
Exhibition:
0.35mm infrared ceramic emitter heater
