20-40hp Mini Tractors With Front End Loader

FOB Price

US$ 5,300 - 6,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Certificate	CE
Brand Name	GOLE	Place of Origin	Henan, China
After-sales Service Provided	Engineers available to service machinery overseas

20-40hp mini tractors with front end loader

Main Technical Specifications
Model			TY254
Type			4×4 Wheeled Type
	Length		2768
	Width		1514
	Height		1365
	Front Wheel	1000/1200
Dimensions	Tread	Rear Wheel	1000-1300 Adjusted
of Tractor	Wheel Base		1512/1598
(mm)			266
	Min. Ground Base
Dry Mass(kg)			1130
Engine	Model		295
	Type		Vertical, 2-cylinder, Water Cooled and 4-stroke
	Rated Power(kw)		18.4
	Rated Rev.(r/min)		2400/2500
	Fuel		Diesel Oil
Tire	Front Wheel		6.00-12/6.00-16
	Rear Wheel		8.30-24/9.50-24
Clutch			Dry-friction, Single Stage or Dry-friction, Two Stage
Steering			Mechanical Type or Hydraulic Type
Transmission Box			(3+1)×2 or (4+1)×2 or (4+1)×2×2(with Creeping Shift)
			Rear three-point suspension O Class A or Class I
Suspension Type
PTO	Type and Rev.(r/min)		Non-independent Type 540 or Non-independent Type 540/1000, 540/720 or Semi-independent Type 540/1000,540/720
	Spline Size		I35 Rectangle Spline with 6 teeth(6×28.91×34.79×8.69)

TZ03D front Loader for tractor20-40hp

1. used to scoop up loose materials, such as dirt, sand or gravel, from the ground and move to another place without pushing them across the ground;

2. Equip with various type of buckets and other implements ;

3. Euro Quick Hitch and Skid Steer quick- release frame(SSP) is optional, rapid assembly and disassembly;

4. easy processing and convenient;

5. smartest design engineers, experienced weld technicians, and brilliant research and development teams

6. sleek low-profile shape provides clearer sightlines and amazing visibility in all directions

7. OEM service is acceptable, products can be customized.

Loader Model			TZ03D
Matching Tractor		HP	20-40
Max.Lifting Height at Implement Pivot Pin	H	mm	2550
Dumpling Height	A	mm	1840
Overloading height	L	mm	2370
Dumpling Distance	W	mm	500
Ground Clearance at Arm Pivot Pin	B	mm	1200
Max.Tip in Angle	X	Degree°	48
Tip out Angle	Z	Degree°	58
Crowd angle at lowered lift arm	V	Degree°	135
Digging depth	S	mm	100
Lifting Force at Implement Pivot Pin	Q1	kg	2224
	Q2	kg	1474
Bucket Model(Standard)			04DP125
Bucket Width		mm	1250
Bucket Capacity		m3	0.18
Rated Lifting Capacity		kg	300
