compact non-pressured solar water heat
- 3000 Set / Sets per Month
- Shanghai/Ningbo
- T/T Credit Card
You May Like
Product Details
Place of Origin | Zhejiang, China | Brand Name | OEM/OU'SUN | |
Type | Non-Pressure | Application | Water Heater | |
Pipe Material | Glass |
Product Description
compact non-pressured solar water heat
This system uses the thermosiphon principle, Solar vacuum tube is pluged into the bottom of water tank,
The water is filled inside the solar vacuum tube, Solar vacuum tube transmit solar energy to heat energy,
The temperature of water inside solar vacuum tube is rising, As the thermosiphon principle, the hot water
rise up, and arrive in the water tank, the cold water inside the water tank go down the solar vacuum tube,
so the system runs by this circulation way until the water become very hot. The highest temperature of water
tank can be 95 degree Celsius, During this process, this system doesn't need any power, just under the
sunshine. It is a green product
Specification:
1. Water tank inner shell: 0.4~0.5mm SUS304-2B (food grade stainless steel).
2. Water tank outer shell: 0.4mm colored steel or 0.4 mm SUS304-2B.
3. Stand: galvanized steel with painting, or aluminium alloy, or stainless steel.
4. Water tank heat insulation layer: 50~60 mm polyurethane foam.
5. Stand angle: 15 degree, 20 degree, 25 degree, 30 degree, 38 degree, 45 degree.
Descripition | compact non-pressured solar water heat |
Material of out tank | 0.31-0.4mm thickness color steel/ fluorine carbon steel/sus304 |
Material of inner tank | Food grade 0.31-0.4mm thickness SUS304 stainless steel |
Tank insulating layer | 55mm 45kg/m³ high-density polyurethane foamed |
Inlet and outlet hole | Male G 1/2, 3/4 |
Max pressure | 0.05 Mpa |
Solar collector tube | 3.3 Borosilicate glass Cu/SS-ALN(H)/SS-ALN(L)/ALN coated |
Thickness of glass tube | 1.6mm |
Vacuum tube tightness | P<0.005 Pa |
Absorption | as=0.93-0.96(AM1.5) |
Emission ratio | eh=0.04-0.06(80C±5C) |
Idle sunning property parameters | Y=220~260m2.C/KW |
Average heat loss coefficient | ULT=0.6~0.7W/(m2.C) |
Bracket: | 1.5mm thickness Galvanized Steel or 201 steel |
Structure of tank: | 4 holes for exhaust port, overflow, water inlet and outlet, electric heater is option |
Welding: | Argon arc welding |
Fastening pieces: | stainless steel screw |
The main business of our company is three kinds of solar water heaters, there are compact non-pressurized solar water heater, split pressurized solar water heater and heat pipe compact solar water heater.
If you are interested in our products, welcome to enter our home page for more details.
We Design, Manufacture and deliver the sun’s unlimited and cheapest energy to your daily life.OU’SUN Solar Energy Technology Co., Ltd, With more than 10 years development and technology bring in, Products are acceptable and popular in foreigner country with serious quality control, on time delivery and good export service.
Sample order: we will use wooden box for package.
Container order: We will use high quality export carton for package.
Pre-sale Service
1. Sample can be offered with sample charge and courier fee by buyer's side.
3. OEM and ODM order are accepted, Any kind of logo printing or design are available.
4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you
5. All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
6. We have rich experience of design, manufacture and sell solar water heater, we cherish every order from our honor.
After you choose
1. We will count cheapest shipping cost and make invoice to you at once.
2. Check quality again, then send out to you at 1-2 working day after your payment,
3. Email you the tracking no, and help to chase the parcels until it arrive you.
After-sale service
1. We are very glad that customer give us some suggestion for price and products.
2. If any question,please contact with us freely by E-mail or Telephone.
1- What is your Delivery Time?
7days for samples load
10days for container load
2- Can you accept OEM ?
YES
3- What is your Payment Term?
We accept T/T or L/C at sight
4-What is your MOQ?
1 sets
5-What is your Price Term?
FOB, CFR and CIF acceptable
