compact non-pressured water solar heater

FOB Price

USD $86 - $320 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

solar boiler solar water heater
1.For 5years warranty
2.For 2% free spare parts
3.Sample offer
4.high quality

compact non-pressured water solar heater

working principle:

This system uses the thermosiphon principle, Solar vacuum tube is pluged into the bottom of water tank,

The water is filled inside the solar vacuum tube, Solar vacuum tube transmit solar energy to heat energy,

The temperature of water inside solar vacuum tube is rising, As the thermosiphon principle, the hot water

rise up, and arrive in the water tank, the cold water inside the water tank go down the solar vacuum tube,

so the system runs by this circulation way until the water become very hot. The highest temperature of water

tank can be 95 degree Celsius, During this process, this system doesn't need any power, just under the

sunshine. It is a green product

Specification:

1. Water tank inner shell: 0.4~0.5mm SUS304-2B (food grade stainless steel).

2. Water tank outer shell: 0.4mm colored steel or 0.4 mm SUS304-2B.

3. Stand: galvanized steel with painting, or aluminium alloy, or stainless steel.

4. Water tank heat insulation layer: 50~60 mm polyurethane foam.

5. Stand angle: 15 degree, 20 degree, 25 degree, 30 degree, 38 degree, 45 degree.

Descripition	compact non-pressured water solar heater
Material of out tank	0.31-0.4mm thickness color steel/ fluorine carbon steel/sus304
Material of inner tank	Food grade 0.31-0.4mm thickness SUS304 stainless steel
Tank insulating layer	55mm 45kg/m³ high-density polyurethane foamed
Inlet and outlet hole	Male G 1/2, 3/4
Max pressure	0.05 Mpa
Solar collector tube	3.3 Borosilicate glass Cu/SS-ALN(H)/SS-ALN(L)/ALN coated
Thickness of glass tube	1.6mm
Vacuum tube tightness	P<0.005 Pa
Absorption	as=0.93-0.96(AM1.5)
Emission ratio	eh=0.04-0.06(80C±5C)
Idle sunning property parameters	Y=220~260m2.C/KW
Average heat loss coefficient	ULT=0.6~0.7W/(m2.C)
Bracket:	1.5mm thickness Galvanized Steel or 201 steel
Structure of tank:	4 holes for exhaust port, overflow, water inlet and outlet, electric heater is option
Welding:	Argon arc welding
Fastening pieces:	stainless steel screw

Product display:
