55L Thermoplastic Hand-liner for Marking
- China Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Security Rs Series Thermoplastic Line Marking Machine For Sale
-
Special Purpose Vibra Line Automatic Big Thermoplastic Convex Road Marking Machines
-
Crosswalk Urban Roads Automatic Line Hot Painting Machine Price
-
High Quality Machines for Road Marking Thermoplastic
-
RS Series Thermoplastic Spray Machine Prices
-
Good Performance Thermoplastic Striping Machine
Product Details
| Condition | New | Power(W) | No engine | |
| Place of Origin | China | Brand Name | ROADSKY hand-liner | |
| Model Number | RS-1A/B hand-liner | Dimension(L*W*H) | 1420*9000*1050 mm/ 1200*800*1020 mm | |
| Weight | 145kg / 120 kg(NET) | Features | Convenient and reliable | |
| Certification | ISO9001:2008, CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
55L Thermoplastic Hand-liner for Marking
1.General Description
Hand Push Thermoplastic Road Machine is special purpose equipment for road marking.
It is used for highway,road axis, lane line, community, airport, etc. to mark all sorts of thermoplastic lines,
such as straight line, dotted line, curve, oriented arrow, and letters.
RS-1A Hand Push Thermoplastic Road Marking Machine
Road Marking width: It is fit for marking 50/80/100/120/150/180/200/230/250/300/400/450 mm width
thermoplastic lines and we can produce any Dies for marking any other width thermoplastic lines according to your requirement.
RS-1B Hand Push Thermoplastic Road Marking Machine
Dies: The structure plate is made of imported special steel with fire resistance (2000°C), oxidation resistance and deformation resistance, which has better stability after being punched.The nice manufacture techniques of dies ensure the ease of operation, moving steadily, good effect, even marking thickness, neat marking line, durability and firmness.
Glass beads dispenser: The automatic definite quantity dispenser synchronous with the paint screeding system, ensures the dispenser more even and more economical. The structure of the glass bead dispenser’
disposition is advanced, compact, flexible, and ease of operation.
2.Technical Parameters
Model | RS-1A | RS-1B |
Capacity of Paint Tank | 55 L / 100 kg | 55 L / 100 kg |
Capacity of Glass Beads Bin | 10 kg | 10 kg |
Dies | 50/80/100/120/150/180/200/230/250/300/400/450 mm | |
Size (L×W×H) | 1420*900*1050 mm | 1200*800*1020 mm |
Net Weight | 145kg | 120 kg |
Heating Fuel | carry 10 kg to 15 kg liquefied petroleum gas with one gas tank | |
Thickness of Bottom Line | 1-3 mm | |
Marking Speed | 500-1200 m/h | |
3.Main Components
4.Driving Type Thermoplastic Road Marking
Machine
RS1A and RS1B Hand Push Thermoplastic Road Marking Machine can be connected
with the RS11Booster Vehicle, so that you can drive the machine for road marking.
It will save the manpower and enhance the working efficiency greatly.
5.Additional Parts
The spare parts for thermoplastic road marking machines include
different sizes of dies and glass bead dispensers, burners, tubes, lighting torch,
ground knifes, and so on.
6. On-site Working
7. Other Related Products
All standards thermoplastic paint and glass bead (BS, AASHTO, CS and etc)
can be manufactured as request.
Our Thermoplastic Paint Preheater is professional equipment for melting hot paint.
It has the advantage of large capacity, saves heating time, also greatly improves stirring efficiency.
8. Road Marking Auxiliary Machine
For more information, please contact us or check our website:
.
