Home > Products > speaker drivers > 15" Speaker driver
15" Speaker driver
Negotiable
/ Piece
10 Pieces(Min.Order)
- 3000 Piece / Pieces per Month
- Guangzhou
- Credit Card PayPal
You May Like
Product Details
| Model Number | SW-15072 Woofer | Type | Passive | |
| Use | Stage | Place of Origin | Guangdong, China |
Product Description
| SW-15072 Woofer | |
| 1000W continuous program power capacity 99.3mm copper voice coil 35-2000 Hz response 96 dB Sensitivity | |
| Specifications | |
| Nominal Diameter | 460mm(18in) |
| Nominal Impedance | 8Ω |
| Minimum Impedance | 7.2Ω |
| Power Handling | |
| (90-900 Hz) | |
| Nominal | 550W |
| Continuous Program | 1100W |
| Sensitivity (1W/1m) | 98dB |
| Frequency Range | 35-2000 Hz |
| Voice Coil Diameter | 99.3mm |
| Winding Material | Copper |
| Former Material | KSV |
| Winding Depth | 22mm |
| Magnetic Gap Depth | 12mm |
| Flux Density | 1.2T |
| Also available in 16Ω, data upon request | |
| Thiele & Small Parameters | |
| Fs | 37 Hz |
| Re | 5Ω |
| Qes | 0.32 |
| Qms | 12.5 |
| Qts | 0.31 |
| Vas | 226dm3 |
| n 0 | 1.00% |
| X max | ±5mm |
| X var | ±6mm |
| Mms | 214.7g |
| B1 | 25.6Tm |
| Le | 1.9mH |
| Mounting and Shipping Information | |
| Overall Diameter | 462mm |
| Bo 1t Circle Diameter | 474mm |
| Baffie Cutout Diameter | 435mm |
| Ddepth | 210mm |
| F 1 ange and Gasket Thickness | 15.5mm |
| Net Weight | 13kg |
| Shipping Weight | 14kg |
| Shipping BOX | 500×500×250mm |
| 2hours test made with continuous pink noise signal(6 dB crest factor) within the speicifled range, Power calculated on rated minimum impedance, Loudspeaker mounted In 35 liters(1.25ft3) bass-refiex box, tuned at 65Hz. | |
| Power on Continuous Program is defined as 3 dB greater than the Nominal rating. | |
| Applied RMS Voltage is set to 2.83V for 8 ohms Nominal impedance, average SPL from 100 to 1000 Hz. | |
| Thiele-Small parameters are measured after a high level 20 Hz sine wave preconditioning test. | |
