Product Details
| Place of Origin | Guangdong, China | Brand Name | SUNBOW | |
| Model Number | SB-STCP | Type | Other, Flexible, Seal type or open type | |
| Material | PE |
Product Description
SUNBOW Split Wall Corrugated Loom Tubing Orange
Model Number: SB-STCP SB-OTCP
Material: PE, PP, PA
Working temperature: -30ºC ~ +100ºC (PE material)
-40ºC ~ +110ºC (PP material)
-40ºC ~ +125ºC (PA material)
Structure: wavy shape both interior and exterior.
Performance
Good flexibility, abrasion resistance, acid resistance, fire resistance, etc.
Usage
It can be used in machinery, electrical equipment, foodstuff machinery, automatic meters and gauges and
motors as abrasion and insulation protection for cables.
Dimension
Material | Item No. | Size (mm) | Packing | Rm±10% | |
Inner Diameter | Outer Diameter | ||||
PE, PP, PA Seal or Open Type Corrugated Pipe | AD7.5 | 5.5 | 7.5 | 200 | 10 |
AD10 | 7.0 | 10.0 | 100 | 15 | |
AD13 | 10.0 | 13.0 | 100 | 20 | |
AD15.8 | 12.0 | 15.8 | 100 | 25 | |
AD18.5 | 14.3 | 18.5 | 100 | 30 | |
AD21.2 | 17.0 | 21.2 | 100 | 35 | |
AD25 | 20.0 | 25.0 | 100 | 40 | |
AD28.5 | 23.0 | 28.5 | 100 | 45 | |
AD34.5 | 29.0 | 34.5 | 50 | 55 | |
AD42.5 | 36.0 | 42.5 | 25 | 65 | |
AD54.5 | 48.0 | 54.5 | 25 | 85 | |
Color: Standard color is black (other color available upon request).
1) ISO 9001:2008 approved;
2) 10 years exporting experience;
3) 15 years manufacturing experience;
4) Other products certificates: UL E360625 for heat shrink tube, silicone rubber tube; E333178 and E333177 for silicone fiberglass sleeve; ROHS, REACH, CQC.
1. What is the MOQ?
1000 meters.
2. What is the payment terms?
T/T 100% in advance.
