Recessed COB LED Downlights angle adjustable 20W

Model No

Description

XT-DB-012

XT-DB-015

XT-DB-020

Power(W)

12W±10%

15W±10%

20W±10%

Input voltage(V)

AC90-260 50/60Hz

AC90-260 50/60Hz

AC90-260 50/60Hz

Power factor (PFC)

>0.95

>0.95

>0.95

Initial luminous(LM)

>840

>1050

>1400

Light efficiency(LM/W)

>70

>70

>70

Beam angle(Θ)

15,24,38,60

15,24,38,60

15,24,38,60

CCT(K)

2700-6500K

2700-6500K

2700-6500K

CRI(Ra)

>80

>80

>80

Color of lamp body

White / White+black

White / White+black

White / White+black

Angle adjustable

12º adjustable

12º adjustable

12º adjustable

Dimmable

----

----

----

Materials

Aluminum

Aluminum

Aluminum

IP Rate

IP20

IP20

IP20

Lamp size(mm)

Φ138*H93

Φ138*H93

Φ138*H117

Cut hole(mm)

Φ120

Φ120

Φ120

Working temperature

-25°~+45°

-25°~+45°

-25°~+45°

Storage temperature

-30°~+50°

-30°~+50°

-30°~+50°

Warranty

3 years

3 years

3 years

1). OEM/ODM Service

Our strong and professional R&D dept. can develop different products for different target prices and different requirements.

2). Free sample service

Samples can be free.

The cost for any samples can be deducted from the amount in quantity order.

3). Direct factory, Competitive price

We are the real manufacturer.Factory price, various products we can make for you.

4). Quality control

We have a strict quality control system, Professional QC team.

No matter the inner packing or the outer carton.

We can design as your request.

All requests will be reply within 12 hours.

Contact Us at Any Time

Company Name: Fujian Province Jingyi Xintai Electronics Co.,Ltd.

Factory: Xiandian Industrial Zone, Wuyishan, Nanping, Fujian, China

Xiamen Branch: A306,No.1505, Fanghu North 2nd Rd. Huli,Xiamen,China

 Tel:  0086 0592 5717969
