Hot Sale LPF Model Power Pallet Truck-LPF25 Made In China

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China		Brand Name	Cheuk's
Model Number	LPF25		Lift Drive / Actuation	Electric Motor

Product Description

The specification of hand pallet truck LPF25

Identifica tion	1.1	Manufacturer`s type designation	Unit	LPF25
	1.2	Drive:electric(battery or mains),diesel,petrol,fuel gas,manual		electric
	1.3	Type of operation :hand , pedestrian, standing, seated, order-picker		standing
	1.4	Load Capacity / rated load	Q(kg)	2500
	1.5	Load centre distance	C(mm)	600
	1.6	Load distance ,centre of drive axle to fork	x(mm)	800
	1.7	Wheelbase	y(mm)	1390
Weights	2.1	Service weight	(kg)	1100
	2.2	Axle loading,laden front/rear	(kg)	1510/2090
	2.3	Axle loading,unladen front/rear	(kg)	935/165
Wheels, Chassis	3.1	Tyres:solid rubber,superelastic,pneumatic,polyurethane		polyurethane
	3.2	Tyre size,front	(mm)	φ254×82
	3.3	Tyre size,rear	(mm)	φ84×93
	3.4	Additional wheels(dimensions)		φ100×40
	3.5	Wheels,number front/rear(x=driven wheels)		1x +2/ 4
	3.6	Track width,front	b10(mm)	560
	3.7	Track width,rear	b11(mm)	380
Basic Dimensions	4.1	Lift height	h3(mm)	130
	4.2	Height of tiller in drive position min./max.	h14(mm)	1230
	4.3	Lowered height	h13(mm)	85
	4.4	Overall length	l1(mm)	2432
	4.5	Length to face of forks	l2(mm)	1282
	4.6	Overall width	b1(mm)	800
	4.7	Fork dimensions	s/e/l(mm)	60/180/1150
	4.8	Width over forks	b5(mm)	560
	4.9	Ground clearance,centre of wheelbase	m2(mm)	25
	4.10	Aisle width for pallets 800X1200 lengthways	Ast(mm)	2632
	4.11	Turning radius	Wa(mm)	2100
Performan ce	5.1	Travel speed,laden/unladen	km/h	8/9
	5.2	Lift speed, laden/unladenm	m/s	34/45
	5.3	Lowering speed,laden/unladenm	m/s	35/20
	5.4	Max.gradient performance,laden/unladen	%	6/14
	5.5	Service brake		electromagnetic
E-Motor	6.1	Drive motor rating s2 60min	kw	3.0(AC)
	6.2	Lift motor rating at s3 7%	kw	2.2
	6.3	Battery voltage,nominal capacity	V/Ah	24/360
Others	7.1	Type of drive control		MOSFET Control
Others	7.2	sound level at driver`s ear acc.to EN 12053	dB(A)	67

Company Information

Shanghai Cheuk's Logistics Technology Co., Ltd.,which is subordinate to Cheuksgroup, is specializing in the developing, manufacturing and marketing of logistics, lifting and hydraulic machinery. We have abundant product line, forklift truck, pallet truck, stacker, table lift, tail gate, tow trackor, aerial work platform,plastic hand truck, hydraulic tools and so on.

Our sales and network covers all over the world, also R&D center in Germany and America. We keep a really good relationship with our abroad partners. We based in China, supply you with our standard products of reliable quality, reasonable price. Also,the OEM service is available according to your requirements. Give us an opportunity, we will "Lifting your future"!
